Sheep Following System

This repository contains a ROS2 package for following sheep using YOLO object detection. The system provides two different approaches: high-level navigation using Nav2 and low-level velocity control.

Demos

Repository Structure

yolo_sheep_follower/
├── sheep_follower/                    # Main ROS2 package
│   ├── package.xml
│   ├── setup.py
│   ├── setup.cfg
│   ├── resource/
│   ├── sheep_follower/                # Python source code
│   │   ├── __init__.py
│   │   ├── nav2_sheep_follower.py
│   │   ├── direct_sheep_follower.py
│   │   └── wolf_distance_detector.py
│   ├── launch/
│   │   ├── sheep_follower_simulation.launch.py
│   │   ├── nav2_sheep_follower.launch.py
│   │   └── direct_sheep_follower.launch.py
│   └── config/
│       ├── nav2_sheep_follower.yaml
│       ├── direct_sheep_follower.yaml
│       └── sheep_follower.rviz
├── deps/                              # Git submodules
│   ├── yolo_ros/                      # YOLO ROS2 (includes yolo_msgs)
│   └── gps_ignition_simulation/       # Gazebo worlds & robot models
├── logos/
├── .gitignore
├── .gitmodules
├── CITATION.cff
└── README.md

Installation

# Clone with submodules
cd ~/ros2_ws/src
git clone --recursive https://github.com/luispri2001/yolo_sheep_follower.git

# Install ROS dependencies
cd ~/ros2_ws
rosdep install --from-paths src --ignore-src -r -y

# Build
colcon build --symlink-install

# Source
source install/setup.bash

Note: If you cloned without --recursive, run: git submodule update --init --recursive

Quick Start - Complete Simulation

Launch the full sheep following simulation with one command:

ros2 launch sheep_follower sheep_follower_simulation.launch.py

This launches:

• Gazebo Ignition with campus world and sheep
• LeoRover robot
• Nav2 navigation stack
• YOLO 3D detection
• Sheep follower node

Simulation Parameters

ros2 launch sheep_follower sheep_follower_simulation.launch.py \
  sheep_id:=any \
  yolo_model:=yolov8m.pt \
  yolo_device:=cuda:0 \
  use_rviz:=true

Parameter	Default	Description
sheep_id	any	Target sheep ID or "any" to follow first detected
yolo_model	yolov8m.pt	YOLO model to use
yolo_device	cuda:0	Device for inference (cuda:0, cpu)
use_rviz	true	Launch RViz with visualization
use_sim_time	true	Use simulation time

Note: The system accepts both "sheep" and "cow" detections since YOLO may confuse them in simulation.

Requirements

• ROS2: Humble / Iron
• Python: 3.8+
• OS: Ubuntu 22.04

Dependencies (auto-installed via rosdep)

• nav2_msgs, geometry_msgs, tf2_ros, tf2_geometry_msgs
• vision_msgs, std_msgs, visualization_msgs, sensor_msgs
• cv_bridge, numpy, opencv-python
• yolo_msgs (included as submodule)

Overview

This system implements autonomous sheep following capabilities for robotic applications in agricultural and research environments. It uses YOLO-based 3D object detection to identify and track specific sheep by ID or any sheep in the field.

Components

1. Nav2 Sheep Follower (nav2_sheep_follower.py)

A high-level navigation approach that uses the Nav2 navigation stack to follow sheep. This implementation is ideal for complex environments requiring path planning and obstacle avoidance.

Features

• High-level navigation: Uses Nav2's NavigateToPose action for robust path planning
• Transform handling: Properly handles coordinate transformations between frames
• Goal optimization: Avoids sending redundant navigation goals
• Graceful recovery: Continues to last goal when sheep detection is lost
• Configurable parameters: Adjustable timeouts, tolerances, and target frames

Parameters

• target_frame (default: "map"): Target coordinate frame for navigation
• lost_timeout (default: 2.0s): Time before considering sheep lost
• goal_tolerance (default: 0.5m): Minimum distance between goals to send new command
• goal_offset (default: 1.0m): Distance to maintain from sheep position

Usage

# Run with launch file (recommended)
ros2 launch sheep_follower nav2_sheep_follower.launch.py sheep_id:=3

# Or run the node directly
ros2 run sheep_follower nav2_sheep_follower --id 3

# Follow any sheep (default - follows first detected and sticks with it)
ros2 run sheep_follower nav2_sheep_follower --id any

Architecture

YOLO Detections → TF Transformations → Goal Calculation → Nav2 Action Client

2. Direct Velocity Sheep Follower (direct_sheep_follower.py)

A low-level approach that directly controls robot velocity using cmd_vel commands. This implementation provides more immediate response and fine-grained control.

Features

• Direct velocity control: Publishes Twist messages to /cmd_vel
• Distance-based behavior: Adjusts speed based on proximity to target
• Visual servoing: Uses both 3D position and 2D image coordinates for control
• Safety mechanisms: Automatic stopping when target is lost
• Real-time control: High-frequency control loop (10Hz)

Parameters

• max_linear_speed (default: 0.3 m/s): Maximum forward/backward speed
• max_angular_speed (default: 0.6 rad/s): Maximum rotation speed
• min_follow_distance (default: 2.5m): Minimum distance to maintain
• max_follow_distance (default: 5.0m): Maximum following distance
• center_threshold (default: 30 pixels): Tolerance for centering target
• lost_object_timeout (default: 2.0s): Time before stopping when target lost

Usage

# Run with launch file (recommended)
ros2 launch sheep_follower direct_sheep_follower.launch.py sheep_id:=3

# Or run the node directly
ros2 run sheep_follower direct_sheep_follower --id 3

# Follow any sheep (default - follows first detected and sticks with it)
ros2 run sheep_follower direct_sheep_follower --id any

Control Logic

• Linear velocity: Based on distance to target (approach/retreat/maintain)
• Angular velocity: Combination of 3D lateral offset and 2D image centering
• Safety: Automatic stop when target lost or invalid data received

Configuration

Launch Parameters

You can customize the behavior of the nodes with launch file parameters:

# For Nav2 follower
ros2 launch sheep_follower nav2_sheep_follower.launch.py \
  sheep_id:=3 \
  target_frame:=map \
  lost_timeout:=3.0 \
  goal_tolerance:=0.7 \
  use_sim_time:=true

# For Direct velocity follower
ros2 launch sheep_follower direct_sheep_follower.launch.py \
  sheep_id:=3 \
  max_linear_speed:=0.4 \
  min_follow_distance:=2.0 \
  use_sim_time:=true

Configuration Files

YAML configuration files in config/:

• nav2_sheep_follower.yaml
• direct_sheep_follower.yaml

Dependencies

ROS2 Packages

• rclpy: ROS2 Python client library
• geometry_msgs: For Twist and PoseStamped messages
• nav2_msgs: For NavigateToPose action
• yolo_msgs: Custom YOLO detection messages
• tf2_ros: Transform library
• tf2_geometry_msgs: Geometry message transformations
• vision_msgs: Vision-related message definitions

Input Topics

• /detections_3d (yolo_msgs/DetectionArray): 3D YOLO detection results
• /tracking (yolo_msgs/DetectionArray): YOLO tracking results with IDs

Output Topics

• Nav2 Sheep Follower: /navigate_to_pose (nav2_msgs/NavigateToPose)
• Direct Velocity Follower: /cmd_vel (geometry_msgs/Twist)

---

Wolf Distance Detector (wolf_distance_detector.py)

This node detects wolves using YOLO detections and publishes both the estimated 3D distance to the wolf and a visualization. It also publishes an annotated image with the 2D bounding box and distance overlay.

Features

• Wolf detection: Identifies wolves in YOLO detection messages
• Distance estimation: Calculates and publishes the 3D distance to the detected wolf
• RViz visualization: Publishes 3D bounding box and distance as markers
• Annotated image: Publishes a camera image with the wolf's 2D bounding box and distance overlay

Topics

Topic	Type	Description
/wolf/distance	std_msgs/Float32	Distance to the detected wolf
/wolf/visualization	visualization_msgs/MarkerArray	Markers for RViz
/wolf/image_detection	sensor_msgs/Image	Annotated image with bounding box

Usage

ros2 run sheep_follower wolf_distance_detector

Visualization

To visualize the wolf detection and distance in RViz:

1. Run the wolf_distance_detector node.
2. In RViz, add a "Marker" display type and subscribe to the /wolf/visualization topic.
3. Add a "Image" display type and subscribe to the /wolf/image_detection topic for annotated images.

Citation

If you use this software, please cite the following paper:

@inproceedings{herds2025,
  title     = {HERDS: A ROS 2-based animal detection and herding system},
  author    = {Prieto-L{\'o}pez, Luis and Mayoko Biong, Jean Chrysostome and
               S{\'a}nchez de la Fuente, Sergio and Gonz{\'a}lez-Santamarta, Miguel A. and
               Rodr{\'i}guez-Lera, Francisco J. and S{\'a}nchez-Gonz{\'a}lez, Lidia},
  booktitle = {Proceedings of the Eight Iberian Robotics Conference (ROBOT 2025)},
  year      = {2025},
  month     = {November},
  publisher = {IEEE Press},
  address   = {Porto, Portugal}
}

Acknowledgments

This project has been partially funded by the Recovery, Transformation, and Resilience Plan, financed by the European Union (Next Generation), thanks to the AURORAS project, and by grant PID2024-161761OB-C21 funded by MICIU/AEI/10.13039/501100011033 and by the ERDF/EU.
