🛰️ recon-deck

From nmap output to an actionable, port-aware recon checklist in under 30 seconds. Offline. Self-hosted. Every engagement export-ready as Markdown.

---

Paste nmap text / XML / greppable output — or drag in an AutoRecon results/ zip — and every open port becomes a card with pre-filled commands (IP interpolated), HackTricks links, tickable checks, evidence screenshots, and a notes field.

Built for OSCP / HTB students and solo pentesters who currently juggle 8 browser tabs and a scratch Obsidian file per box.

_{▶ Watch the 50-second demo — paste nmap → drill into a port → tick checks → switch ports.}

_{An engagement view: 28 open ports, KB-matched risk colors, per-port check completion. More screenshots →}

# 30-second smoke test — pulls the image, starts on http://localhost:13337
curl -sSL https://raw.githubusercontent.com/kocaemre/recon-deck/main/install.sh | sh

---

Why recon-deck

Without it	With it
8 browser tabs per box (HackTricks, payloadsallthethings, gtfobins, …)	One page per port, prefilled commands ready to copy
Hand-typing nmap -p- -sV boilerplate per service	KB-driven commands with {IP} / {HOST} / {PORT} / {WORDLIST_*} placeholders
Lost track of which checks you ran on box #7	Tickable checklist + per-port notes saved in SQLite
Markdown report = manual copy-paste from notes	One-click export: Markdown / HTML / JSON / SysReptor / PwnDoc / PDF
AutoRecon dump → folder spelunking	Drop the zip, every per-port file routed to the right card

---

Feature highlights

📥 Ingest — nmap text / XML / greppable + AutoRecon zip + manual ports

• Multi-format nmap parser — -oN, -oX, -oG. Multi-host scans become a host-selector chip in the header
• AutoRecon zip import — drag the results/ folder zipped; per-port service files, _manual_commands.txt, gowitness screenshots, patterns / errors logs all routed automatically
• Re-import + diff — re-paste a fresh nmap output and the heatmap badges new ports NEW and previously-open ports CLOSED. Header scans: N chip tracks how many imports you've done
• Manual ports — heatmap + Add port for services nmap missed (DNS zone transfer, alt banners, etc.)

🎯 Triage — KB-driven port cards, known-vulns, searchsploit, findings catalog

• KB-driven cards — port + service + product/version match shipped YAML KB → tickable checks, prefilled commands, HackTricks links
• Active Directory toolkit — nxc (netexec), impacket (GetNPUsers, GetUserSPNs, secretsdump), kerbrute, bloodhound-python, PetitPotam, pyWhisker — all wired to the right DC ports (88/135/389/445/464/636/3268/3389/5985)
• Known-vulns auto-match — vsFTPd 2.3.4 and friends → vuln + CVE + ref link surfaces on the port card
• searchsploit lookup — one-click searchsploit -t "<product>" per port, cached
• Findings catalog — severity / title / description / CVE / evidence refs. One-click + finding button on KB rows pre-populates the modal

🖼️ Evidence — per-port screenshots, AutoRecon gowitness import, native annotation

• Drag-drop / clipboard-paste screenshots into a per-port evidence pane
• Native HTML5 canvas annotation — Box / Arrow / Pencil / Text tools, 5-color palette, undo stack. Save chains a new evidence row via parent_evidence_id so the original always survives
• AutoRecon gowitness / aquatone PNGs auto-import into the matching port's evidence list

📤 Export — Markdown, JSON, HTML, CSV, SysReptor, PwnDoc, print-to-PDF

• Six export formats plus a print-optimised PDF route
• Markdown ships with Obsidian-compatible frontmatter
• SysReptor JSON + PwnDoc YAML for reporting-tool feeds
• Findings CSV for spreadsheet triage
• Multi-host aware — SysReptor scope and PwnDoc scope list every host; markdown / HTML render one section per host

⌨️ Workflow — command palette, FTS5 search, keyboard shortcuts, sidebar actions

• Command palette (⌘K) — every UI action lives in the palette: add finding, re-import, settings, delete, exports, print
• Cross-engagement search (⌃⇧F) — FTS5 + BM25, hit rows show host context
• Sidebar engagement actions — hover-kebab with rename / duplicate (deep-copy) / delete (shadcn AlertDialog)
• Custom commands + wordlist overrides at /settings/commands and /settings/wordlists — your snippets surface alongside KB commands

📚 Knowledge base — YAML KB, in-app editor, hot-reload

• YAML KB — drop entries in /kb (or wherever you point kb_user_dir); shipped KB lives under knowledge/
• In-app editor at /settings/kb — paste, validate against the Zod KbEntrySchema, save under a strict filename allowlist
• Hot reload — fs.watch on shipped + user dirs flips a dirty flag, next request rebuilds. Edit a YAML in your editor, refresh, see your change
• In-app editor at /settings/kb — paste, validate, save (atomic write under a strict [A-Za-z0-9_-] filename allowlist)

🛡️ Safety — migration backup, host-header allowlist, rate limiter, offline-by-default

• Pre-migration snapshots via VACUUM INTO — boot writes data/recon-deck.db.backup-pre-NNNN before any new migration runs. Failure logs surface a copy-pasteable cp rollback line
• Post-migration PRAGMA integrity_check + foreign_key_check — either failing aborts boot
• Host-header allowlist middleware — defends DNS-rebinding when the app is reachable on 0.0.0.0
• Per-IP rate limiter on /api/* — defense-in-depth for the LAN-exposure case
• Offline by default — zero outbound HTTP unless the operator opts in to the GitHub release check

🚀 First-run (v2.1.0) — onboarding, sample engagement, update toast

• /welcome 4-step onboarding — scope · tour · local paths · updates. Seeds the app_state singleton with your local_export_dir, kb_user_dir, wordlist_base, and the release-check toggle
• Replay onboarding from /settings → First-run — paths preserved
• Sample engagement — "Try sample" on the paste panel inserts a canned 10-port HTB-easy box marked is_sample = true. Header surfaces a SAMPLE chip + single-click Discard
• Notify-only update check (opt-in) — pings api.github.com/repos/kocaemre/recon-deck/releases/latest once per session, toasts a "Release notes" link if a newer tag exists. Installs stay manual
• Desktop-only viewport guard — < 1280px shows a clean "needs a wider screen" explainer

---

Quick Start

Three ways to run, pick one. All bind to 127.0.0.1:13337 (port picked to dodge the dev-server crowd on 3000/8080), so nothing leaks to your LAN by default; see Exposing to LAN if you need otherwise.

1. One-liner (auto-pulls + starts + opens browser):

curl -sSL https://raw.githubusercontent.com/kocaemre/recon-deck/main/install.sh | sh

2. Docker Compose (recommended for persistent setups):

curl -O https://raw.githubusercontent.com/kocaemre/recon-deck/main/docker-compose.yml
docker compose up -d

3. Manual docker run:

docker run -d --name recon-deck -p 127.0.0.1:13337:13337 \
  -v recondeck-data:/data \
  -v recondeck-kb:/kb \
  -e HOSTNAME=0.0.0.0 \
  ghcr.io/kocaemre/recon-deck

Open http://localhost:13337, paste nmap output, see cards. The -p 127.0.0.1:13337:13337 host-side prefix keeps the app loopback-only — see Exposing to LAN for LAN reachability.

---

What it is / What it is NOT

For OSCP/HTB students and solo pentesters. Offline. No LLM. Does not run scans — it complements AutoRecon and HackTricks. Think of it as the OSCP-flavored Obsidian for recon: same category as Obsidian, focused on post-scan workflow.

It is NOT a reporting platform, a team tool, a scanner, an AI assistant, or a mobile app. The intent is deliberate and narrow — see ROADMAP.md for the out-of-scope list.

---

Exposing to LAN

By default, the Quick Start binds to 127.0.0.1 on the host — only your local machine can reach the app. To make recon-deck reachable from another machine on your LAN:

docker run -p 13337:13337 \
  -v recondeck-data:/data \
  -v recondeck-kb:/kb \
  -e HOSTNAME=0.0.0.0 \
  -e RECON_DECK_TRUSTED_HOSTS=192.168.1.10:13337 \
  ghcr.io/kocaemre/recon-deck

Replace 192.168.1.10:13337 with the host:port your LAN clients will use. RECON_DECK_TRUSTED_HOSTS is comma-separated — expand it for every additional host you want to reach the app from.

This activates the host-header allowlist (mitigates DNS rebinding). Requests whose Host: header is not in the allowlist are rejected with HTTP 421 Misdirected Request. See SECURITY.md for the full threat model.

---

Customizing the Knowledge Base

Drop YAML files into /kb/ports/*.yaml (volume-mounted) — they override shipped entries with the same port/service at startup. Schema, denylist, and placeholder syntax in CONTRIBUTING.md.

Bind-mounting a host dir? Container runs as UID 1000 — chown 1000:1000 /path/to/my-kb first, or use a named volume (-v recondeck-kb:/kb) which inherits ownership automatically.

---

AutoRecon Import

1. autorecon <target> → produces results/<ip>/
2. cd results && zip -r my-target.zip <ip>/
3. Drag the zip onto the import panel

Server-side unzip routes everything: per-port files (tcp80/…, tcp_22_ssh_*) into the right card, _manual_commands.txt into Manual commands, gowitness/aquatone PNGs into port evidence, log files (_patterns, _errors, _commands) into an engagement warning panel. Multi-IP zips become multi-host engagements (primary inherits full AR data, secondaries get ports + scripts).

---

Multi-host engagements

One engagement, N hosts (DC + workstations, related boxes, etc.). Hosts chip-switch in the header; heatmap + commands + palette all rescope. Multi-host is detected from XML <host> blocks, text/greppable Nmap scan report for ... boundaries, and AutoRecon multi-IP zips.

---

Re-import + scan diff

Hit Re-import in the engagement header and paste a fresh nmap output. The reconciler:

• Adds new ports (NEW chip on the heatmap)
• Refreshes last_seen_scan_id for re-observed ports
• Marks ports the new scan didn't see as closed (CLOSED chip, dim tile)
• Surfaces a scans: N chip in the header so you know multi-import diff context applies
• Toast: 1 new · 1 closed · 2 unchanged after import

---

Settings

/settings (footer link in the sidebar) covers:

• Engagement list — inline delete with cascade confirmation
• Wordlists (/settings/wordlists) — override {WORDLIST_*} placeholders
• Custom commands (/settings/commands) — personal snippets alongside KB commands, scopable by service/port
• KB editor (/settings/kb) — paste, validate, save to your user dir; cache invalidates immediately

Engagement renames are inline on the header (target identity) or via the sidebar kebab (display label). The kebab also exposes Duplicate (deep-copy transaction) and Delete (cascade with confirmation).

---

Exports

Six formats + a print route. All multi-host aware.

Format	Use
Markdown	Obsidian-compatible frontmatter, paste into your vault
JSON	Structured dump for scripting
HTML	Standalone single-file report, opens offline
Findings CSV	Severity / host / port / CVE rows for spreadsheets
SysReptor JSON	projects/v1 shape with scope[]
PwnDoc YAML	Findings + scope, multi-host aware
Print-to-PDF	/report route, Ctrl+P → Save as PDF

---

Backup & Restore

State lives in two volumes — back both up together:

• recondeck-data → SQLite DB (history, evidence, findings, notes)
• recondeck-kb → your YAML overrides under /kb

Snapshot to tarball:

docker stop recon-deck
docker run --rm -v recondeck-data:/data -v recondeck-kb:/kb -v "$(pwd)":/out \
  alpine sh -c 'tar -C / -czf /out/recon-deck-$(date +%F).tar.gz data kb'
docker start recon-deck

Restore: stop + rm container, recreate volumes, tar -xzf from inside an alpine container, restart. Migrations re-apply on boot. Pin a specific image tag (ghcr.io/kocaemre/recon-deck:v2.1) for production restores so a :latest jump doesn't surprise you.

Boot also takes a VACUUM INTO 'data/recon-deck.db.backup-pre-NNNN' snapshot before running pending migrations; on failure the log prints a copy-pasteable rollback line. Schema is forward-only — see CONTRIBUTING.md › "Migration safety and recovery" for the full procedure.

---

Upgrading

Notify-only — no auto-update, no telemetry. Optional release check is opt-in at /settings → First-run.

Docker (easy): the install one-liner is idempotent — re-run it to upgrade. It pulls the new image, removes the prior container (named volumes survive), and starts fresh:

curl -sSL https://raw.githubusercontent.com/kocaemre/recon-deck/main/install.sh | sh

Docker (manual):

docker pull ghcr.io/kocaemre/recon-deck:latest
docker stop recon-deck && docker rm recon-deck
# re-run docker run from Quick Start; named volumes survive

Local dev: git pull && npm install && npm run dev. Migrations apply at boot.

Tech Stack

Layer	Technology
Framework	Next.js 15.5 (App Router)
UI	React 19, Tailwind 4, shadcn/ui
Persistence	SQLite via Drizzle + better-sqlite3
Parsers	fast-xml-parser (XML), custom regex (text)
KB format	YAML via js-yaml, validated by Zod
Container	node:22-alpine, multi-stage build
License	MIT

Full version pins live in package.json. The image is a single multi-stage node:22-alpine build — typical pulled size is under ~200 MB.

---

Development

For local hacking outside the container:

git clone https://github.com/kocaemre/recon-deck
cd recon-deck
npm install
npm run dev
# → http://localhost:13337

Useful scripts:

npm test              # vitest unit tests (parsers + KB schema)
npm run lint:kb       # YAML lint (schema + denylist + URL scheme)
npm run typecheck     # tsc --noEmit
npm run build         # production build (output: "standalone")

---

Configuration Reference

Env var	Default	Purpose
HOSTNAME	127.0.0.1	Bind address inside the container. Override to 0.0.0.0 for port-map reach.
PORT	13337	Port the app listens on (also drives the host-header allowlist default).
RECON_DB_PATH	/data/recon-deck.db	SQLite file location. Keep on a mounted volume for persistence.
RECON_KB_USER_DIR	/kb	User KB directory. Onboarding writes this to app_state.kb_user_dir which takes precedence; env var is the fallback.
RECON_LOCAL_EXPORT_DIR	(empty)	Engagement header's vscode://file/… link. app_state.local_export_dir wins; this and NEXT_PUBLIC_RECON_LOCAL_EXPORT_DIR are fallbacks.
RECON_DECK_TRUSTED_HOSTS	(empty)	Comma-separated extra hosts allowed by the host-header middleware.
NEXT_TELEMETRY_DISABLED	1	Disables Next.js telemetry. Preserves the offline guarantee.

---

Contributing

See CONTRIBUTING.md for KB rules, PR discipline, and what's in/out of scope.

Security

See SECURITY.md for the threat model, offline guarantee, and default-deny postures.

Credits

See CREDITS.md for upstream attribution — HackTricks, AutoRecon, PayloadsAllTheThings, SecLists.

Roadmap

See ROADMAP.md for upcoming candidates, the v2.x future direction, and hard out-of-scope items.

License

MIT.
