gpui-devtools

Inspect and debug GPUI applications with an element picker, layout information, source locations, computed values, and style details.

The inspector includes:

• an element picker
• source locations and GPUI element IDs with copy actions
• a box model view with element bounds, content size, margin, border, and padding
• a computed values panel with measured bounds, content size, explicit dimensions, spacing, opacity, visibility, and background
• temporary quick style edits for the selected Div, including presets, incremental size/spacing/opacity controls, background, visibility, reset, and copy/export actions
• grouped Div style refinements with compact spacing and color previews
• a global toggle action and optional default keybinding

Install

[features]
devtools = ["dep:gpui-devtools", "gpui/inspector"]

[dependencies]
gpui = { package = "gpui-pre", version = "0.3" }
gpui-devtools = { version = "0.5", optional = true }

GPUI DevTools 0.5 targets gpui-pre 0.3, the crates.io snapshot of Zed's GPUI also used by gpui-kit. Your application must resolve to the same GPUI crate, otherwise Cargo builds two incompatible copies.

gpui-devtools	GPUI
0.5	gpui-pre 0.3
0.4	gpui-pre 0.3
0.3	gpui-pre 0.3
0.2	gpui 0.2

Use

app.run(|cx| {
    // Initialize the rest of the app first.

    #[cfg(feature = "devtools")]
    gpui_devtools::init(cx);
});

Install GPUI DevTools after libraries that register their own inspector renderer.

The default shortcut is cmd-alt-i on macOS and ctrl-alt-i elsewhere. You can dispatch gpui_devtools::ToggleInspector yourself or customize installation:

gpui_devtools::init_with(
    gpui_devtools::Config::default().key_binding(None),
    cx,
);

Roadmap

• deeper style inspection and live editing
• better element navigation, selection, and source discovery
• visual debugging helpers such as repaint and layout overlays
• focus, keybinding, action, and event inspection
• render, layout, and paint diagnostics
• entity and lifecycle debugging tools

License

MIT
