Soccerize - Realtime football commentary app

Soccerize Football is full-stack, event-driven real-time football simulation app supporting real-time goals, cards (yellow or red), and commentary powered by AWS services- Simple Queue Service(SQS), Lambda, DynamoDB, DynamoDB Stream, WebSocket APIs, along with Express Server and React with Vite.

Screenshots

Home page UI

Scoreboard View

Table of Contents

• About
• Architecture
• Tech Stack
• CI/CD Pipeline
• Getting Started
• License

About

Soccerize is a real-time football commentary and scoring app powered by:

• WebSocket (AWS API Gateway)
• AWS SQS + Lambda + DynamoDB Streams
• CI/CD with Jenkins, GitLab, ArgoCD
• Kubernetes (KIND - in kind-cluster branch/EKS in eks-deploy branch)

Architecture

AWS Infrastructure & Traffic Flow

This diagram illustrates how the entire AWS infrastructure is set up — including VPC, subnets, worker nodes, ALB, traffic routing, SQS, Lambda, DynamoDB, and WebSocket delivery.

Application Runtime & CI/CD Pipeline

This diagram shows how the React frontend, Node.js backend, AWS services, and the CI/CD pipeline (Jenkins + GitLab + ArgoCD) work together to deliver real-time updates.

Tech Stack

Frontend

• React.js (Vite) – Uses React with Vite
• WebSocket Client – On load of frontend, auto-connects to WedSocket API for real-time commentary

Backend

• Node.js + Express.js – Handles API endpoints for goals/cards events and sends events to AWS SQS
• AWS SDK (v3) – Publishes messages and interacts with AWS services programmatically

AWS Services

• Amazon SQS – Buffers real-time football events before processing
• AWS Lambda –
  • Event Processor Lambda: Consumes SQS messages and inserts them into DynamoDB
  • Broadcaster Lambda: Triggered by DynamoDB Streams to push commentary to clients
• Amazon DynamoDB – Stores event data(goal/card) and active WebSocket connections
• DynamoDB Streams – Emits changes to trigger the Broadcaster Lambda
• API Gateway (WebSocket) – Pushes commentary to all connected frontend clients in real time

Containerization

• Docker – Containerizes all services (frontend and backend) for consistent builds
• Docker Compose – (Optional for local testing) Spins up multi-container environments

Kubernetes (K8s)

• Amazon EKS – Cluster provisioned via eksctl with managed node groups in private subnets
• Ingress Controller (ALB) – Routes external traffic to internal services securely
• ConfigMaps & Secrets – Injects runtime variables and credentials securely into pods

CI/CD Pipeline

• GitLab – Source control with branches: dev, kind-cluster, and eks-deploy
• Jenkins CI –
  • Pulls code on push to eks-deploy branch
  • Runs SonarQube for code quality and Trivy for files scanning (DevSecOps)
  • Builds and tags Docker images through passed parameters
  • Pushes images to Docker Hub
• Jenkins CD –
  • Updates Kubernetes manifests with the new Docker image tag passed down from Jenkins CI
  • Commits and Pushes back to GitLab (GitOps)
• ArgoCD – Setup ArgoCD server, creates an application, watches the Git repo and syncs updated manifests to EKS cluster

Monitoring & Alerts

• Prometheus – Collects metrics from Pods, Nodes, and Services
• Grafana – Visual dashboards for observability
• Email Notification – Sent on Jenkins job completion (success/failure)

CI/CD Pipeline

Fully automated workflow powered by GitLab, Jenkins, ArgoCD, and GitOps best practices.

1. Developer Pushes Code

• Developer pushes to the eks-deploy branch in GitLab
• Developer manually triggers the Jenkins CI pipeline by passing the frontend and backend image tag as parameters.

2. Jenkins CI Job

• Clones the repository
• Runs static code analysis using SonarQube
• Scans the project files with Trivy for vulnerabilities
• Builds Docker images for frontend and backend
• Tags the images based on version
• Pushes images to Docker Hub

3. Jenkins CD Job

• Uses the new image tag as input
• Updates Kubernetes manifests with the new tag
• Commits and pushes updated manifests back to the GitLab repo

4. GitOps with ArgoCD

• ArgoCD watches the GitLab repository
• On detecting new changes:
  • Pulls updated manifests
  • Syncs them to the EKS Kubernetes cluster

5. Monitoring & Alerts

• Prometheus collects metrics from pods and nodes
• Grafana visualizes metrics in real-time dashboards
• Email alerts are sent on CI/CD success or failures

DevSecOps Integrated

• Code Quality → SonarQube
• Image Vulnerability Scans → Trivy
• GitOps-Style Deployment → ArgoCD

Getting Started

Soccerize is a real-time football commentary application that provisions AWS resources using Infrastructure-as-Code (Terraform).

• Remote state management (via S3 & DynamoDB) is used for core services: SQS, Lambda, DynamoDB, WebSocket API.
• Local state files are used for foundational infrastructure like VPC, Subnets, and EC2.

---

Step 1: Bootstrap Remote Backend

First, we need to create an S3 bucket and a DynamoDB table to store Terraform state remotely and lock it during execution. Location: ~/projects/soccerize/bootstrap/main.tf

cd ~/projects/soccerize/bootstrap
terraform init
terraform apply

This provisions

• soccerize-tf-state S3 bucket for storing .tfstate remotely
• soccerize-tf-lock DynamoDB table for state locking

Step 2: Provision Core AWS Services (Lambda, SQS, DynamoDB, WebSocket API)

Location: ~/projects/soccerize/infrastructure (Remote state is used here)

cd ~/projects/soccerize/infrastructure
terraform init
terraform apply

This provisions

• SQS queues
• DynamoDB tables
• Lambda functions
• WebSocket API Gateway
• IAM roles and permissions

Step 3: Provision Network and Bastion Host

Location: ~/projects/soccerize/scripts/provision-dev-bastion.sh (Local state file used here) Instead of running Terraform manually, I have used a script to automate provisioning and extract outputs like VPC ID, subnets, and Bastion IP.

cd ~/projects/soccerize/infrastructure/envs/dev
terraform init
terraform apply

This script does the following:

1. Navigates to infrastructure/envs/dev/ and runs:

   • terraform init
   • terraform apply -auto-approve

2. Provisions the following AWS resources:

   • VPC
   • Public & Private Subnets
   • NAT Gateway
   • EC2 Bastion Host
   • Security Groups

3. Captures important Terraform outputs automatically:

   • vpc_id
   • private_subnets → extracts Subnet A & Subnet B
   • bastion_public_ip
   • key_pair_name

4. Generates Kubernetes config files using the captured outputs and environment variables:

   • cluster-config.yml
   • nodegroup-config.yml

   Generation is done using envsubst:

   envsubst < cluster-config.tpl.yml > cluster-config.yml
   envsubst < nodegroup-config.tpl.yml > nodegroup-config.yml

• Two files gets generated under ~/projects/soccerize/infrastructure/eks-cluster cluster-config.yml and nodegroup-config.yml

Connect to the Bastion Host

Once the script finishes running, you’ll see your VPC ID, Subnets, Bastion EC2 public IP and SSH key name printed in the terminal.

To connect to the Bastion from your local machine:

ssh -i ~/projects/soccerize/key-name ubuntu@<BASTION_PUBLIC_IP>

Step 4: Install Required Tools (Locally) on your EC2

Update and Install Essentials

sudo apt update && sudo apt upgrade -y
sudo apt install -y git unzip curl jq build-essential

Install Docker

sudo apt update
sudo apt install docker.io -y
sudo systemctl enable --now docker
sudo usermod -aG docker $USER && newgrp docker

Verify Docker:

docker ps

Install AWS CLI

The AWS CLI is required to authenticate and interact with AWS resources from your local terminal.

Install AWS CLI v2 (Linux)

curl "https://awscli.amazonaws.com/awscli-exe-linux-x86_64.zip" -o "awscliv2.zip"
unzip awscliv2.zip
sudo ./aws/install
rm -rf awscliv2.zip aws/

Verify AWS

aws --version

Configure Credentials

aws configure

Provide your AWS Access Key ID, AWS Secret Access Key, Default Region, and Output format.

Install kubectl (Kubernetes CLI)

kubectl is the command-line tool used to interact with your Kubernetes clusters.

Install kubectl (Linux)

curl -LO "https://dl.k8s.io/release/v1.33.2/bin/linux/amd64/kubectl"
chmod +x kubectl
sudo mv kubectl /usr/local/bin/

Verify kubectl

kubectl version

Install eksctl (Amazon EKS CLI)

eksctl is the official CLI tool for managing Amazon EKS clusters. We'll use it to create and configure our Kubernetes cluster in AWS.

Install eksctl (Linux)

curl -sL "https://github.com/eksctl-io/eksctl/releases/latest/download/eksctl_$(uname -s)_amd64.tar.gz" | tar xz -C /tmp
sudo mv /tmp/eksctl /usr/local/bin

Verify eksctl

eksctl version

Create EKS Cluster from Bastion (via GitLab)

We'll create the EKS cluster from our Bastion EC2 instance using configuration files stored in a GitLab repository.So far, we’ve generated but not pushed cluster-config.yml and nodegroup-config.yml. First, push those files to your GitLab repo before proceeding.

Step1: Generate SSH Key (inside Bastion EC2)

This key allows the Bastion to securely connect to GitLab and clone your repo.

ssh-keygen -t rsa -C "<your_email>" -f ~/.ssh/gitlabkey

Generated files:

• ~/.ssh/gitlabkey → private key
• ~/.ssh/gitlabkey.pub → public key

Step2: Add the Public Key to the Gitlab

1. Go to GitLab > User Settings > SSH Keys
2. Paste the content of ~/.ssh/gitlabkey.pub and click Add Key

Step 3: Add the private key to SSH agent

eval $(ssh-agent -s)
ssh-add ~/.ssh/gitlabkey

Step 4: Clone your repo from GitLab

mkdir -p ~/projects
cd ~/projects
git clone -b eks-deploy git@gitlab.com:<your-username>/<your-repo>.git
cd soccerize
git branch
#you should see eks-deploy

Files to look for:

• eks-cluster/ ├── cluster-config.yml └── nodegroup-config.yml

Create the EKS Cluster

cd eks-cluster
eksctl create cluster -f cluster-config.yml

Verify Cluster

kubectl version

If you see this error: Unable to connect to the server: dial tcp ... i/o timeout It means the Bastion cannot reach the EKS control plane (port 443 is blocked).

Fix Security Group Ingress from Bastion to EKS Cluster SG

aws ec2 authorize-security-group-ingress \
  --group-id <CLUSTER-SG-ID> \
  --protocol tcp \
  --port 443 \
  --source-group <BASTION-SG-ID> \
  --region <DEFAULT-REGION>

Verify again

kubectl version

Expected: Client Version: v1.33.2 Server Version: v1.30.x-eks-xxxxx You're now fully connected to the EKS cluster from Bastion

Step 5: Update kubeconfig (So kubectl can talk to the cluster)

After the cluster is created, run the following command from the Bastion EC2 instance:

aws eks update-kubeconfig --name <CLUSTER-NAME> --region <DEFAULT-REGION>

This command:

• Retrieve the cluster details from AWS
• Add or update the kubeconfig file at ~/.kube/config
• Allow kubectl to authenticate with the EKS API

Step 6: Verify Kubernetes Default Services

Run the following command to list all services running in the default namespace:

kubectl get svc

• Returns the default Kubernetes Service of TYPE CLUSTER IP- the virtual IP of the Kubernetes Service.

Create NodeGroup from Bastion

• Provisions worker nodes based on your nodegroup-config.yml

eksctl create nodegroup -f nodegroup-config.yml

Verify Nodes

kubectl get nodes

• Provisions two worker nodesacross two AZ's inside private subnets.

Install AWS Load Balancer Controller

Step1: Associate Your AWS Account With OIDC Provider

eksctl utils associate-iam-oidc-provider --region <DEFAULT-REGION> --cluster <CLUSTER-NAME>> --approve

Step2: Download the AWS ALB IAM Policy

curl -o iam_policy.json https://raw.githubusercontent.com/kubernetes-sigs/aws-load-balancer-controller/main/docs/install/iam_policy.json

Step3: Create IAM Policy

aws iam create-policy \
  --policy-name AWSLoadBalancerControllerIAMPolicy \
  --policy-document file://iam_policy.json

Step4: Create IAM Service Account for ALB Controller

eksctl create iamserviceaccount \
  --cluster=soccer \
  --region=us-east-1 \
  --namespace=kube-system \
  --name=aws-load-balancer-controller \
  --attach-policy-arn=arn:aws:iam::211125312142:policy/AWSLoadBalancerControllerIAMPolicy \
  --approve

Step5: Install Helm

curl https://raw.githubusercontent.com/helm/helm/master/scripts/get-helm-3 | bash

Step6: Add EKS Helm Chart Repo

helm repo add eks https://aws.github.io/eks-charts
helm repo update

Step7: Install the AWS Load Balancer Controller via Helm

helm upgrade -i aws-load-balancer-controller eks/aws-load-balancer-controller \
  -n kube-system \
  --set clusterName=<CLUSTER-NAME>> \
  --set serviceAccount.create=false \
  --set serviceAccount.name=aws-load-balancer-controller \
  --set region=<DEFAULT-REGION>> \
  --set vpcId=<VPC ID> \
  --set image.tag="v2.7.1"

Verify Deployment

kubectl get deployment -n kube-system aws-load-balancer-controller

Deploy All Kubernetes Resources (Frontend + Backend + Ingress)

kubectl apply -f namespace/
kubectl apply -f configmaps/
kubectl apply -f secrets/
kubectl apply -f deployments/
kubectl apply -f service/
kubectl apply -f ingress-resource/

Important- Update Public Subnets in ingress-resource/ YAMLs For frontend-ingress.yaml and backend-ingress.yaml, update the annotation:

annotations:
  alb.ingress.kubernetes.io/subnets: <PUBLIC-SUBNET1>,<PUBLIC-SUBNET2>
  alb.ingress.kubernetes.io/target-type: ip
  #These are the public subnet IDs from your VPC, generated during the bastion + network provisioning phase (infrastructure/envs/dev)
  #Copy those values and paste into both Ingress YAMLs.

Verify ALB Ingress

kubectl get ingress -n soccerize-app

---

Install Docker

sudo apt update
sudo apt install -y docker.io
sudo systemctl start docker
sudo systemctl enable docker

Install Jenkins

Update & Install Java (JRE)

sudo apt install -y openjdk-17-jre

Add Jenkins Repo and Install

curl -fsSL https://pkg.jenkins.io/debian-stable/jenkins.io-2023.key | sudo tee \
  /usr/share/keyrings/jenkins-keyring.asc > /dev/null

echo deb [signed-by=/usr/share/keyrings/jenkins-keyring.asc] \
  https://pkg.jenkins.io/debian-stable binary/ | sudo tee \
  /etc/apt/sources.list.d/jenkins.list > /dev/null



sudo apt update
sudo apt install jenkins -y

#Start and Enable Jenkins
sudo systemctl start jenkins
sudo systemctl enable jenkins


#Check Status
sudo systemctl status jenkins


#Access Jenkins
 http://<EC2-PUBLIC-IP>:8080
#Retrive the Jenkins Password
sudo cat /var/lib/jenkins/secrets/initialAdminPassword

Install Trivy

Install Required Packages

sudo apt update
sudo apt install -y wget apt-transport-https gnupg lsb-release

Add Trivy APT Repo and GPG Key

wget -qO - https://aquasecurity.github.io/trivy-repo/deb/public.key | \
  sudo gpg --dearmor -o /usr/share/keyrings/trivy.gpg

echo "deb [signed-by=/usr/share/keyrings/trivy.gpg] \
  https://aquasecurity.github.io/trivy-repo/deb \
  $(lsb_release -cs) main" | \
  sudo tee /etc/apt/sources.list.d/trivy.list > /dev/null

Install Trivy

sudo apt update
sudo apt install -y trivy

Verify Installation

trivy --version

Run SonarQube in Docker

docker run -itd \
  --name sonarqube \
  -p 9000:9000 \
  -e SONAR_ES_BOOTSTRAP_CHECKS_DISABLE=true \
  -v sonarqube_data:/opt/sonarqube/data \
  -v sonarqube_extensions:/opt/sonarqube/extensions \
  sonarqube:lts-community

Verify SonarQube

docker ps

Access SonarQube Web UI

http://<EC2-PUBLIC-IP>:9000
#Default login Username admin Password admin

Install OWASP & DevSecOps Plugins on Jenkins

1. Go to Jenkins Dashboard → Manage Jenkins → Plugin Manager → Available Plugins
2. Use the search bar and install these plugins:

• OWASP Dependency-Check Plugin
• SonarQube Scanner
• Docker Pipeline
• Pipeline: Stage View
• Blue Ocean

Integrate Jenkins with SonarQube (DevSecOps Style)

This section explains how to securely integrate Jenkins with SonarQube for the code analysis as part of CI/CD pipeline.

---

Step 1: Generate SonarQube Token (From SonarQube UI)

1. Login to your SonarQube instance:
   http://<EC2-IP>:9000

2. Navigate to:
   Administration → Security → Users → Tokens

3. Click Generate Token

   • Name: jenkins-token (or any name of your choice)

4. Copy the token and save it temporarily.
   we won’t be able to see it again later.

---

Step 2: Add Token to Jenkins as a Secret

1. Open Jenkins and go to:
   Manage Jenkins → Credentials → (Global) → Add Credentials

2. Fill in the following:

   • Kind: Secret text
   • Secret: <paste the token copied from SonarQube>
   • ID: sonar
   • Description: SonarQube Access Token

---

Step 3: Install SonarQube Scanner in Jenkins

1. Navigate to:
   Manage Jenkins → Global Tool Configuration
2. Scroll down to SonarQube Scanner section.
3. Configure the tool:
   • Name: SonarScanner
   • Check Install automatically

---

Step 4: Add SonarQube Server to Jenkins

1. Go to:
   Manage Jenkins → Configure System

2. Find the SonarQube servers section.

3. Add the following:

   • Name: SonarQube
   • Server URL: http://<EC2-IP>:9000
   • Server authentication token: Select the sonar credential added earlier

---

Step 5: Register Jenkins Webhook in SonarQube

1. Visit SonarQube Webhooks:
   http://<EC2-IP>:9000/admin/webhooks

2. Click Create and fill in:

   • Name: jenkins-webhook
   • URL: http://<JENKINS-EC2-IP>:8080/sonarqube-webhook/

3. Click Save

The webhook ensures that SonarQube sends analysis results back to Jenkins after scanning is complete.

---

Integrate Jenkins with GitLab

This section explains how to integrate GitLab with Jenkins

---

Step 1: Create Personal Access Token in GitLab

1. Login to your GitLab account.
2. Navigate to:
   User Settings → Access Tokens
3. Fill in the token details:
   • Name: gitlab-token
   • Scopes: read_repository, write_repository, api
4. Click Create Personal Access Token.
5. Copy and store the token securely.
   we won’t be able to see it again once we leave the page.

---

Step 2: Add GitLab Token to Jenkins

1. Open Jenkins and go to:
   Manage Jenkins → Credentials → (Global) → Add Credentials
2. Select:
   • Kind: Username with password
   • Username: <your-gitlab-username>
   • Password: <paste the GitLab personal access token>
3. Provide:
   • ID: GitlabCred
   • Description: GitLab PAT for Jenkins Integration
4. Click OK to save.

---

Step 3: Connect GitLab with Jenkins

Follow the steps below to integrate GitLab with Jenkins:

Step 3.1 : Install GitLab Plugin

1. Navigate to Jenkins → Manage Jenkins → Plugins.
2. Under the Available tab, search for: GitLab Plugin.
3. Select and install the plugin.
4. Restart Jenkins if prompted.

---

Step 3.2: Configure GitLab Connection

1. Go to Jenkins → Manage Jenkins → Configure System.

2. Scroll down and find the GitLab section.

3. Fill in the connection details:

   • Connection Name: gitlab
   • GitLab Host URL: https://gitlab.com
   • Credentials:
     • Click Add and enter your GitLab Personal Access Token (PAT).
     • Select the created credential from the dropdown.

4. Click Test Connection to verify the setup.

5. Finally, click Save.

---

---

Install and Configure Argo CD on EC2 (Master Machine)

This section explains:

• Installing Argo CD on our EKS cluster
• Accessing Argo CD UI securely via browser
• Connecting GitLab repository for GitOps operations

---

Step1: Full Setup Instructions

# Step 1: Create Argo CD Namespace
kubectl create namespace argocd

Step 2: Install Argo CD Components

kubectl apply -n argocd -f https://raw.githubusercontent.com/argoproj/argo-cd/stable/manifests/install.yaml

Step 3: Watch Argo CD Pods Come Up

watch kubectl get pods -n argocd

Step 4: Install Argo CD CLI on EC2

sudo curl --silent --location -o /usr/local/bin/argocd \
  https://github.com/argoproj/argo-cd/releases/download/v2.4.7/argocd-linux-amd64
sudo chmod +x /usr/local/bin/argocd

Step 5: Check Argo CD Services

kubectl get svc -n argocd

Step 6: Port Forward Argo CD Server on EC2 (to avoid Jenkins 8080)

kubectl port-forward svc/argocd-server -n argocd 8081:443

Step 7: SSH Port Forward from Your Local Machine

Run this command on your local machine to forward Argo CD to your browser:

ssh -i terra-key -L 8080:localhost:8081 ubuntu@<EC2-PUBLIC-IP>
Then open your browser and go to:
`http://localhost:8080`

Step 8: Log In to Argo CD

Default credentials:

• Username: admin
• Password: Run this command to retrieve it:

kubectl -n argocd get secret argocd-initial-admin-secret \
  -o jsonpath="{.data.password}" | base64 -d && echo

• Use the output password to log in to the Argo CD UI.

Step 9: Reset the Admin Password

After logging in to the Argo CD UI:

1. Click the user icon in the top-right corner.
2. Select Change Password.
3. Enter your Current Password.
4. Enter your New Password.
5. Confirm the New Password.
6. Re-login using your new password.

Step 10: Connect Your GitLab Repository to Argo CD

Inside the Argo CD UI:

1. Navigate to Settings → Repositories → Connect Repo.
2. Fill out the form with the following details:

• Type: Git
• Project: default
• Connection: HTTPS
• Repository URL: <your-gitlab-repo>
• Username: <your-gitlab-username>
• Password (GitLab personal access token): <your-gitlab-PAT>

3. Click Connect

Deploy Application to Argo CD

This section describes the process of creating an Argo CD Application that syncs with your Gitlab repository and deploys a manifest from a specific path ie k8s/dev and branch eks-deploy in EKS Cluster

Prerequisite: Argo CD Cluster Connected

Check connected clusters using:

argocd cluster list

SERVER NAME STATUS MESSAGE https://kubernetes.default.svc in-cluster Successful cluster has no application and is not monitored

Step 1: Create a New Argo CD Application

Follow these steps:

1. Open your browser and go to the Argo CD UI

   Usually accessible via: http://localhost:8080 (Ensure you have an SSH port-forward session running)

2. On the Argo CD dashboard, click on the + NEW APP button in the top menu.

Application Configuration

After clicking NEW APP in the Argo CD UI, fill out the form with the following details:

• Application Name: soccerize-app
• Project Name: default
• Sync Policy: Select Automatic

Tick these boxes:

• PRUNE RESOURCES
• SELF HEAL
• AUTO-CREATE NAMESPACE

Git Repository

Provide the following Git details in the application form:

• Repository URL: <your-gitlab-repo>
• Revision (Branch): <your-brachname>
• Path: k8s/dev<place-where-manifests-live>

Destination Cluster Configuration

• Cluster URL: https://kubernetes.default.svc
• Namespace: <your-namespace-of-soccerizeapp>

Jenkins Shared Library Setup

To configure the Shared Library in Jenkins for your pipeline:

1. Go to Manage Jenkins → System.
2. Search for Global Trusted Pipeline Libraries.
3. Add a new library with the following details:
   • Name: Shared
   • Default Version: eks-deploy<your-gitlab-repo-branch-name>
   • Project Repository: <jenkins-shared-lib><which-we-will-create-in-next-step>
   • Credentials: Select your GitLab credentials (<your-gitlab-credential>)
4. Save the configuration. Your Jenkins pipeline can now use this shared library for deployments.

Jenkins Shared Library Setup and Usage Guide

This guide explains how to create and use a Jenkins Shared Library repository hosted on GitLab for reusable pipeline code.

1. Create the GitLab Repository

• Create a new repository in GitLab named jenkins-shared-lib.
• Initialize it with a README (optional).

---

2. Clone the Repository Locally

Open your terminal and run locally:

cd ~/projects
git clone <gitlab-repo-url-for-jenkins-shared-lib>
cd jenkins-shared-lib

3. Setup Directory Structure, Commit and Push to eks-deploy branch

git checkout -b eks-deploy
mkdir vars
cd vars
git add vars/*.groovy
git commit -m "Add reusable pipeline scripts for eks-deploy"
git push origin eks-deploy

4. Usage in Pipeline

At the top of your Jenkins pipeline script, include the shared library by adding:

@Library('Shared') _
# code
steps #{
      #  build() # Calls build.groovy in vars/
      #}

Docker Hub Token Setup in Jenkins

To enable Jenkins to authenticate with Docker Hub, add your Docker Hub credentials as follows:

Steps to Add Docker Hub Credentials

1. Navigate to Manage Jenkins → Credentials.
2. Add new credentials with the following details:
   • Kind: Username with password
   • Username: <your-dockerhub-username>
   • Password: <your-dockerhub-PAT>
   • ID: docker
   • Description: dockerhub creds
3. Save the credentials.

---

You can now reference these credentials in your Jenkins pipelines using the ID docker.

Jenkins CI/CD Pipeline Setup for Soccerize

This guide explains how to set up two Jenkins pipelines:

• Soccerize-CI – Continuous Integration
• Soccerize-CD – Continuous Deployment

---

Soccerize-CI Pipeline Setup

Create New Item

1. Go to Jenkins → New Item
2. Name: Soccerize-CI
3. Type: Pipeline
4. Click OK

Configuration

• Description: This is a soccerize-ci pipeline
• Tick: Discard old builds
  • Days to keep builds: 1
  • Max builds to keep: 2

This Project is Parameterized

• Check: This project is parameterized
• Add the following String Parameters:
• FRONTEND_DOCKER_TAG
• BACKEND_DOCKER_TAG

GitLab Configuration

• GitLab Connection: Select gitlab from the dropdown (must be configured in Jenkins system config, if not then you need to install Gitlab Pluggins)

Source Control

• Definition: Pipeline script from SCM
  • SCM: Git
  • Repository URL: <your GitLab repository URL>
  • Credentials: <your GitLab PAT credential>
  • Branch Specifier: eks-deploy
  • Script Path: Jenkinsfile

Build Trigger (Optional)

• Check: Trigger builds remotely
• Authentication Token: soccerize-ci-token

---

Soccerize-CD Pipeline Setup

Create New Item

1. Go to Jenkins → New Item
2. Name: Soccerize-CD
3. Type: Pipeline
4. Click OK

Configuration

• Description: This is a soccerize-cd pipeline
• Tick: Discard old builds
  • Days to keep builds: 1
  • Max builds to keep: 2

GitLab Configuration

• GitLab Connection: Select gitlab from the dropdown

Source Control

• Definition: Pipeline script from SCM
  • SCM: Git
  • Repository URL: <your GitLab repository URL>
  • Credentials: <your GitLab PAT credential>
  • Branch Specifier: */eks-deploy
  • Script Path: GitOps/Jenkinsfile

Build Trigger (Optional)

• Check: Trigger builds remotely
  • Authentication Token: soccerize-ci-token

---

Summary

• Soccerize-CI points to the root-level Jenkinsfile
• Soccerize-CD points to GitOps/Jenkinsfile Now we need to write the corresponding pipeline code in each Jenkinsfile

Kubernetes Monitoring with Prometheus & Grafana using Helm

Step 1: Install Helm

curl https://raw.githubusercontent.com/helm/helm/main/scripts/get-helm-3 | bash

Add Prometheus Community Helm Repo

helm repo add prometheus-community https://prometheus-community.github.io/helm-charts
helm repo update

Create monitoring Namespace

kubectl create namespace monitoring

Install Prometheus + Grafana Stack

helm install prometheus prometheus-community/kube-prometheus-stack \
  --namespace monitoring

Accessing the Dashboards

Grafana UI (Port 3000)

kubectl port-forward svc/prometheus-grafana 3000:80 -n monitoring

Now visit: http://localhost:3000 from your local server Default Grafana Credentials:

• Username: admin
• Password: prom-operator

Prometheus UI (Port 9090)

kubectl port-forward svc/prometheus-kube-prometheus-prometheus 9090:9090 -n monitoring

Now visit: http://localhost:9090 from your local server

Remote Access from Local Machine (EC2 SSH Tunnel)

ssh -i terra-key \
  -L 3000:localhost:3000 \
  -L 9090:localhost:9090 \
  ubuntu@<EC2-PUBLIC-IP>

Frontend Metrics

Backend Metrics

License

This project is licensed under the MIT License.
Feel free to use, modify, and distribute this software with proper attribution.
See the LICENSE file for full license details.
