openclaw-workflow

YAML/JSON-driven workflow orchestration for OpenClaw agents.

Compose multi-step agent pipelines with dependency management, parallel execution, retry logic, output gates, cache adoption with contract freshness signatures, explicit handoff completion, and partial resume — all in a declarative YAML file.

---

The Problem

OpenClaw subagents are powerful — but fire-and-forget. There's no native way to:

• Run agent B only after agent A succeeds
• Run agents A and B in parallel, then agent C when both finish
• Retry a flaky step before failing the whole pipeline
• Resume a partially-completed pipeline after a crash
• Validate that a step actually produced the expected output files
• Reuse cached outputs safely when they still match the current contract

Developers work around this with shell scripts, manual timing, and fragile cron chains. openclaw-workflow solves this at the platform level.

---

Installation

# Local development
npm install
npm run build
openclaw plugins install -l . --dangerously-force-unsafe-install

# From npm once published
openclaw plugins install openclaw-workflow --dangerously-force-unsafe-install

--dangerously-force-unsafe-install is currently required because the plugin intentionally imports node:child_process for the CLI session fallback used when OpenClaw does not expose a stable native session API to plugins.

Note: When installing via --link (local development), use the long form --link . rather than the shorthand -l . to avoid a known OpenClaw CLI argument-parsing ambiguity where -l may not be recognized.

---

Sealed Tool-Result Middleware: Patch & Install

Sealed tool_worker steps intercept every tool result before the model sees it, spool the raw payload to the artifact store, and return only a bounded envelope to the model. This requires the plugin to register agentToolResultMiddleware — an API that OpenClaw currently restricts to bundled (first-party) plugins.

Why two steps are needed

Step	Command	What it does
1. Patch	node scripts/patch-openclaw-trust-workflow-middleware.mjs --plugin openclaw-workflow	Edits the OpenClaw gateway/runtime so openclaw-workflow is trusted for registerAgentToolResultMiddleware and Pi middleware receives stable session/run context (sessionId, sessionKey, runId). Without this, OpenClaw either rejects the middleware registration entirely or emits Pi tool_result events without enough identity to resolve the active sealed run reliably.
2. Install	openclaw plugins install --link . --dangerously-force-unsafe-install	Installs the plugin from your local checkout as a linked (symlinked) plugin. --link means OpenClaw loads directly from your working directory — no copy step needed. --dangerously-force-unsafe-install bypasses the unsafe-import check that would otherwise block the plugin because it uses node:child_process.

Full setup sequence (development)

# 1. Build the plugin
npm install
npm run build

# 2. Patch OpenClaw middleware trust + Pi runtime context
node scripts/patch-openclaw-trust-workflow-middleware.mjs --plugin openclaw-workflow

# 3. Install as a linked plugin
openclaw plugins install --link . --dangerously-force-unsafe-install

# 4. Restart the OpenClaw gateway so it picks up the patch and the linked install

Re-run the patch after every OpenClaw update — it only modifies the middleware trust guard and, when a source checkout is available, the Pi embedded-runner middleware context wiring. Use --dry-run to preview what it would change, or --restore to revert:

# Preview changes without writing anything
node scripts/patch-openclaw-trust-workflow-middleware.mjs --plugin openclaw-workflow --dry-run

# Revert the patch
node scripts/patch-openclaw-trust-workflow-middleware.mjs --restore

What the patch actually changes

The script locates the OpenClaw gateway/runtime files that contain the middleware trust guard and patches that guard:

// Before patch:
if (record.origin !== "bundled") { /* reject */ }

// After patch:
if (record.origin !== "bundled" && record.id !== "openclaw-workflow") { /* reject */ }

Nothing else is modified. The patch is idempotent — running it twice is safe.

When the OpenClaw source checkout contains src/agents/pi-embedded-runner/extensions.ts, the same script also patches the Pi tool_result extension boundary so the middleware runner is built with stable identity from sessionManager:

const middlewareCtx = {
  runtime: "pi",
  agentId: sessionManagerAny.agentId ?? sessionManagerAny.agent?.id,
  sessionId:
    sessionManagerAny.sessionId ??
    sessionManagerAny.session?.id ??
    sessionManagerAny.currentSessionId,
  sessionKey:
    sessionManagerAny.sessionKey ??
    sessionManagerAny.session?.key ??
    sessionManagerAny.key,
  runId: sessionManagerAny.runId ?? sessionManagerAny.currentRunId,
};

With OPENCLAW_WORKFLOW_TRACE=1, the patched Pi extension also logs:

[openclaw-trace] pi.tool_result.middleware_context

so you can verify the middleware context before and after the fix.

When middleware is not registered

If the patch was not applied and the middleware registration fails, behavior depends on your config:

• Default (no requireSealedToolResultMiddleware): Plugin starts normally; sealed tool_worker steps that need recordObservationBeforeModel will throw at runtime when they attempt to assert that capability.
• requireSealedToolResultMiddleware: true: Plugin refuses to start entirely, which makes the failure visible at gateway startup rather than at step execution time.

---

Plugin config lives in ~/.openclaw/openclaw.json under plugins.entries."openclaw-workflow".config:

{
  "plugins": {
    "entries": {
      "openclaw-workflow": {
        "enabled": true,
        "config": {
          "workflowsDir": "~/.openclaw/workflows",
          "runsDir": "~/.openclaw/workflow-runs",
          "baseDir": "/home/user/myproject",
          "concurrency": 3,
          "notifyChannel": "telegram",
          "sessionModel": "anthropic/claude-sonnet-4-6",
          "sessionAdapter": "auto",
          "pollIntervalMs": 5000,
          "stateBackend": "auto",
          "redisUrl": "redis://localhost:6379",
          "redisMcpToolPrefix": "MCP_DOCKER",
          "filesystemFallback": true,
          "materializeOutputs": "on_demand",

          "requireSealedToolResultMiddleware": true,
          "sealedMaxPreviewBytes": 2048
        }
      }
    }
  }
}

requireSealedToolResultMiddleware — Set to true (default) after applying the trust patch so the plugin fails at gateway startup if middleware registration is rejected, rather than silently degrading at step runtime. Set to false if you are not using sealed tool_worker steps.

sealedMaxPreviewBytes — Controls how many bytes of each intercepted tool result are inlined into the model context. Everything beyond this limit is spooled to the artifact store and retrievable via workflow_observation_read. Default 2048.

State/artifact backend config notes:

• stateBackend: filesystem | redis | auto | dual (default filesystem)
• redisUrl: enables native Redis backend resolution when configured
• redisMcpToolPrefix: MCP Redis adapter prefix (default MCP_DOCKER)
• filesystemFallback: fallback to file-backed state/artifacts when Redis is unavailable
• materializeOutputs: never | on_demand | always

Redis notes:

• Native Redis mode uses ioredis at runtime (included in this package dependencies).
• MCP Redis mode expects commands exposed as <PREFIX>__get, <PREFIX>__set, <PREFIX>__hset, etc. (for example MCP_DOCKER__get).

Create your workflows directory and restart/verify the gateway:

mkdir -p ~/.openclaw/workflows
openclaw plugins list --verbose
openclaw plugins inspect openclaw-workflow --json
openclaw plugins doctor

On Windows/WSL-mounted directories, OpenClaw may block linked plugins when the source path is reported as world-writable (mode=777). Move or copy the plugin to a non-world-writable path if inspection says the plugin candidate was blocked.

---

Session Adapter Selection

The plugin chooses how to spawn subagent sessions based on the available OpenClaw API surface.

Precedence:

1. OPENCLAW_WORKFLOW_SESSION_ADAPTER environment variable (override)
2. sessionAdapter plugin configuration
3. Default: "auto" (selects the best available)

Available Adapters:

• runtime-subagent (Preferred): Uses the modern api.runtime.subagent SDK.
• legacy-api: Uses the older api.sessions surface.
• cli: Fallback to openclaw CLI cron jobs.
• auto: Tries runtime-subagent $\rightarrow$ legacy-api $\rightarrow$ cli.

If a specific adapter is forced but the required API is missing, the plugin will fail fast with an error.

When a workflow contains sealed tool_worker steps with context firewall enforcement, adapter selection is capability-aware. The selected adapter must support:

• tool-result interception
• transcript firewall
• artifact sink

If those capabilities are unavailable, execution fails before worker spawn (rather than degrading to prompt-only sealing).

---

1. Create a workflow file:

cat > ~/.openclaw/workflows/hello.yml << 'EOF'
name: Hello Pipeline
version: "1.0"
steps:
  - id: greet
    name: "Greeter"
    task: "Write a friendly greeting to output/hello-{date}.txt"
    timeout: 60
    outputs:
      - "output/hello-{date}.txt"

  - id: followup
    name: "Follow-up"
    depends_on: [greet]
    task: "Read the greeting from output/hello-{date}.txt and write a response to output/response-{date}.txt"
    timeout: 60
EOF

2. List available workflows:

workflow_list()

3. Dry run (validate without executing):

workflow_run({ name: "hello", dry_run: true })

4. Run the pipeline:

workflow_run({ name: "hello" })
# → { run_id: "hello-pipeline-20260309T082000", status: "running", ... }

5. Check status:

workflow_status({ name: "hello" })
# → { status: "ok", steps_ok: 2, steps_total: 2, ... }

---

Workflow YAML surfaces

OpenClaw Workflow supports two YAML surfaces:

1. Authoring schema (public)
   Compact, human-friendly workflow format for writing pipelines.

2. Execution schema (internal target)
   Low-level runtime format produced by the compiler.

Authoring workflows are compiled into execution workflows before validation and execution:

authoring YAML -> authoring-loader -> authoring-compiler -> execution WorkflowDefinition -> workflow-loader normalize/validate -> template-schema-validator -> workflow-executor

Raw execution-schema workflow files are disabled in the public load path. For migration-only workflows, use the internal migration loader (loadLegacyExecutionWorkflowForMigrationOnly) rather than normal loadWorkflow / loadWorkflowFromFile.

Security note: trust is based on in-memory compilation, not on YAML metadata. A hand-written __compiled_from field in input YAML is not treated as trusted compiler output.

Authoring example:

schema: authoring
name: Example

collections:
  jobs:
    key: job_id
    queues: [pending, done]

pipeline:
  - collect_jobs:
      uses: browser
      writes: jobs.pending

  - classify_jobs:
      uses: model
      for_each: jobs_ready
      parser: json
      outputs:
        - id: classification_results

  - publish_state:
      uses: plugin
      operation: workflow.state_publish
      state_publish:
        from_step: collect_jobs
        output: jobs_pending
        collection: jobs
        queue: jobs_pending

  - classify_all_jobs:
      uses: drain
      worker_group: classification
      worker:
        uses: model
        task: Classify claimed jobs.
        outputs:
          - id: classified_jobs

Compiled execution outline (abridged):

name: Example
state:
  collections: ...
  queues: ...
  worker_groups: ...
steps:
  - id: collect_jobs
    kind: sealed
    ...
  - id: __publish_jobs_pending_from_collect_jobs
    kind: plugin
    uses: workflow.state_publish
    ...
  - id: classify_jobs
    kind: loop_subagent
    ...
  - id: classify_all_jobs
    kind: state_drain
    ...

### Authoring-specific fields (public schema)

In addition to `resources`, `collections`, `profiles`, and `pipeline`, the authoring schema supports:

- top-level `state` (merged with compiler-generated collection state)
- top-level `required_skills` (public skills only; engine-native state backends remain internal)
- top-level `concurrency` and `version`
- `defaults.sealed` to set global sealed-worker policy overrides

Authoring step additions:

- `outputs` supports rich arrays:
  - string entries (`- jobs_ready`)
  - objects with `id`, `path`, `validate`, `optional`, and `materialize.{path,mode}`
- plugin op shorthand via top-level `operation` (preferred over `with.operation`, still backward-compatible)
- for state plugin specs (`state_publish`, `state_query`, etc.), authoring prefers top-level fields; compiler normalizes compiled/runtime shape to always include `with.state_*` while preserving top-level `state_*` for audit/debug compatibility
- conflicting top-level vs `with.state_*` values are compile-time errors (runtime does not guess)
- public sealed-loop authoring via `for_each` (+ `parser`, `item_schema`) for browser/model steps
- named drain controller authoring via `uses: drain` + `worker_group`, `claim`, `worker`, `complete`
- step-level `sealed` overrides merged over defaults/profile
- `input.claim` for engine-injected bounded claim context (preferred)
- `input_context` as a backward-compatible alias for injected claim context

Example rich output object:

```yaml
outputs:
  - id: jobs_ready
    path: data/linkedin/job-alerts/jobs-ready-{date}.json
    validate: jobs_array
    materialize:
      path: data/linkedin/job-alerts/jobs-ready-{date}.json
      mode: always

## Workflow YAML Schema Reference

### Top-level fields

| Field         | Type     | Required | Default | Description |
|---------------|----------|----------|---------|-------------|
| `name`        | string   | ✅       | —       | Human display name. Used in notifications and slugified for run IDs. |
| `version`     | string   | ❌       | `"1.0"` | Schema version for future compatibility. |
| `description` | string   | ❌       | `""`    | Human description shown in `workflow_list`. |
| `steps`       | array    | ✅       | —       | Ordered list of step definitions. |
| `concurrency` | number   | ❌       | `3`     | Max steps that run in parallel. |
| `state`       | object    | ❌       | —        | Storage backend declaration for state and artifacts. See [Artifact-Backed Declared Outputs](#artifact-backed-declared-outputs). |
| `config`       | object    | ❌       | `{}`     | Top-level configuration variables accessible via `{config.X}` substitution. |
| `validators`    | object    | ❌       | `{}`     | Custom validation rules for output checks, supporting schemas and conditional outcomes (`pass_when`, `retry_when`, `block_when`, `fail_when`). |
| `required_skills` | string[]  | ❌       | `[]`     | Skills required for the entire workflow. Steps without their own `required_skills` inherit these. Injected as instructions into step prompts and verified against agent config. |
| `required_mcp_servers` | string[] | ❌       | `[]`     | External capability servers required by worker steps. Do not list engine-native state backends here. |

`state.contracts` lets you define **semantic state contracts** (for example, collection lifecycle semantics) that the runtime projects to Redis/native state views after outputs validate.

`state.collections`, `state.queues`, and `state.worker_groups` let you define the same lifecycle as named semantic resources for explicit plugin-step state operations such as `workflow.state_publish`, `workflow.state_claim`, `workflow.state_complete`, `workflow.state_query`, `workflow.state_patch_outputs`, `workflow.state_partition`, and `workflow.state_report`.


### Step fields

| Field          | Type      | Required | Default | Description |
|----------------|-----------|----------|---------|-------------|
| `id`           | string    | ✅       | —       | Unique step identifier. Must match `[a-zA-Z0-9_-]+`. Used in `depends_on` references and state files. |
| `name`         | string    | ❌       | Same as `id` | Human display name for notifications. |
| `kind`         | string    | ❌       | inferred | Step execution kind: `subagent`, `loop_subagent`, `plugin`, `state_drain`, or `sealed`. If omitted, loop steps infer `loop_subagent`, drain-controller steps infer `state_drain`, otherwise `subagent`. |
| `task`         | string    | ✅*      | —       | The agent prompt / task description. Supports [variable substitution](#variable-substitution). (*Not required for `kind: plugin` steps or loop containers using `for_each`) |
| `uses`         | string    | ✅**     | —       | Plugin operation ID for `kind: plugin` steps (for example, `workflow.cache_json_document`). |
| `with`         | object    | ❌       | `{}`    | Parameter map passed to a `kind: plugin` operation. Supports [variable substitution](#variable-substitution). |
| `depends_on`   | string[]  | ❌       | `[]`    | IDs of steps that must complete (`ok`) before this step runs. |
| `outputs`      | array     | ❌       | `[]`    | Output validation rules. Supports simple file existence checks or detailed objects with custom validators and schemas. Supports [variable substitution](#variable-substitution). |
| `for_each`     | string\|object    | ❌       | —       | List source for loop expansion. Supports variable/path strings (e.g., `"{songs}"`) and artifact refs (`{ from_step, output }`). |
| `parser`       | string    | ❌       | `"auto"` | Parser to use for the loop list (`"json"`, `"csv"`, `"newline"`, `"auto"`). |
| `item_schema`    | object    | ❌       | —       | Optional schema to validate each item in the loop list (type, required fields, patterns). |
| `steps`        | array     | ❌       | `[]`    | Steps to execute for each item in the `for_each` list. |
 | `model`        | string    | ❌       | Plugin default | LLM model override for this step's session (e.g. `"anthropic/claude-opus-4"`). |
 | `concurrency`   | number    | ❌       | Global limit | Max parallel instances of this specific step. Useful for avoiding rate limits on specific tools/APIs. |
 | `timeout`      | number    | ❌       | `300`   | Maximum execution time in **seconds**. Step is marked failed on timeout. |
| `retry`        | number    | ❌       | `0`     | Number of retry attempts after first failure. `retry: 2` = up to 3 total attempts. |
| `retry_delay`  | number    | ❌       | `30`    | Seconds to wait between retry attempts. |
| `retry_on`     | string[]  | ❌       | `[]`    | Specific failure kinds to retry on (e.g., `["missing_file", "timeout"]`). If empty, only retries when `retryable` is true. |
| `retry_except`  | string[]  | ❌       | `[]`    | Specific failure kinds that prevent retry, even if `retry > 0` or `retry_on` matches. |
| `optional`     | boolean   | ❌       | `false` | If `true`, step failure doesn't fail the pipeline or block dependent steps. |
| `always_run`   | boolean   | ❌       | `false` | If `true`, step runs regardless of dependency failure. |
| `on_block`     | string    | ❌       | `"block_run"` | Behavior when blocked: `"block_run"` (fails pipeline) or `"continue"`. |
| `required_skills` | string[]  | ❌       | `[]`     | Skills required for this specific step. Overrides workflow-level `required_skills`. Injected as instructions into the step prompt and verified against agent config. |
| `required_mcp_servers` | string[] | ❌       | `[]`     | External capability servers required by this worker step. Use `required_skills` (for example `browser-harness`) for skill-level capabilities. |
| `state_contract` | string\|string[] | ❌ | — | Semantic state contract name(s) to project after step outputs validate. The worker only produces outputs; runtime handles Redis/state materialization. |
| `state_publish` | object\|object[] | ❌ | — | Semantic publish specification for `kind: plugin` steps using `workflow.state_publish`. Reads a prior artifact and publishes items into a configured collection/queue. |
| `state_consume` | object | ❌ | — | Semantic consume/claim specification for `kind: plugin` steps using `workflow.state_claim`. Resolves a queue or worker group and emits a claim manifest artifact. |
| `state_reclaim` | object | ❌ | — | Semantic reclaim specification for `kind: plugin` steps using `workflow.state_reclaim_expired`. Requeues expired or orphaned in-flight claims before another worker pass. |
| `state_complete` | object\|object[] | ❌ | — | Semantic completion specification for `kind: plugin` steps using `workflow.state_complete`. Marks claimed items completed/failed using result artifacts from a prior step. |
| `state_query` | object | ❌ | — | Query specification for `kind: plugin` steps using `workflow.state_query`. Produces bounded artifacts from semantic Redis state. |
| `state_partition` | object | ❌ | — | Partition specification for `kind: plugin` steps using `workflow.state_partition`. Splits semantic items into bounded outputs and optional queues. |
| `state_patch_outputs` | object | ❌ | — | Patch specification for `kind: plugin` steps using `workflow.state_patch_outputs`. Merges result artifacts back into semantic Redis documents. |
| `state_report` | object | ❌ | — | Report specification for `kind: plugin` steps using `workflow.state_report`. Produces bounded JSON/Markdown reports from semantic state. |
| `input` | object | ❌ | — | Engine-injected runtime input configuration. Use `input.claim` to inject bounded claim payloads from a dependency claim artifact into worker context. |
| `input_context` | object | ❌ | — | Backward-compatible alias for claim injection config. Prefer `input.claim`. |
| `drain` | object | ❌ | — | Scheduler/controller spec for `kind: state_drain`. Repeatedly expands nested steps until `workflow.state_claim` returns an empty batch. |
| `sealed` | object | ✅* | — | Configuration for `kind: sealed` execution boundary. Required for `kind: sealed`. Supports command-mode execution and worker-mode context-firewall policies. |
| `skip_if_empty` | string    | ❌       | —       | Path to a file that, if missing or containing no valid records (parsed as JSON/CSV/Newline), causes this step to be skipped and marked `ok`. Supports [variable substitution](#variable-substitution). |
| `complete_when` | string    | ❌       | `"session"` | Determines completion criteria: `"session"`, `"outputs"`, `"session_then_outputs"`, `"handoff"`, or `"handoff_or_outputs"`. |
| `signaling` | string | ❌ | auto for `handoff`/`handoff_or_outputs`, otherwise `off` | Controls plugin-injected signaling instructions. `"auto"` injects `workflow_step_update` + `workflow_step_complete` protocol into the runtime prompt so authors don't need to repeat this boilerplate in every step task. `"off"` disables injection for that step. |
| `output_contract_version` | number | ❌ | `null` | Optional explicit contract version for cache freshness signatures. Increment to invalidate older cache artifacts even when files are structurally valid. |
| `reuse_outputs` | object | ❌ | — | Structured cache adoption policy. Supports pre-launch reuse checks with validator + signature freshness gates. |

`**` `uses` is required when `kind: plugin`.

`*` `sealed` is required when `kind: sealed`.

Authoring-first note: in normal user workflows (`schema: authoring`), the compiler emits execution kinds such as `sealed`, `plugin`, and internal `state_drain` controllers. Raw `subagent` / `loop_subagent` execution-schema steps are legacy-only and rejected unless legacy execution loading is explicitly enabled.

### Sealed Steps (`kind: sealed`)

`sealed` is the generic worker primitive for enforcing a data-plane/control-plane split:
- **large/full results** are preserved in artifact storage
- **model context** receives only compact summaries/handles
- declared outputs remain the authoritative contract for step completion

Use `kind: sealed` instead of introducing many specialized worker kinds.

#### Sealed modes

- `tool_worker` (default): isolated worker session with policy hints for result/context handling
- `skill_worker`: same execution surface, authored for skill-centric worker tasks
- `adapter`: reserved adapter-directed worker mode
- `command`: bounded OS command execution with stdout/stderr spool + output-contract checks

`mode` defaults to:
- `command` when `sealed.command` is present
- otherwise `tool_worker`

#### Sealed spec fields

```yaml
sealed:
  mode: tool_worker | skill_worker | adapter | command
  no_model: false

  command:                      # required when mode: command
    argv: ["node", "scripts/transform.mjs"]
    cwd: "."
    env:
      NODE_ENV: production

  tools:
    allow: []
    deny: []

  result_visibility:
    mode: auto
    inline_when_safe: true
    preserve_full_results: true
    spool_when_large: true
    return_refs: true
    lazy_read: true
    expose_preview: true

  context_firewall:
    enabled: true
    strategy: adaptive
    on_context_pressure: spool_and_compact

  tool_result_policy:
    max_context_injection_bytes: auto
    max_single_result_bytes_before_spool: auto
    include_head_bytes: 512
    include_tail_bytes: 512
    preserve_full_result: true
    mode: auto

  stdout_policy:
    max_stdout_bytes: 2048
    max_stderr_bytes: 4096
    max_process_output_bytes: 104857600
    mode: spool_and_summarize

  watchdog:
    mode: progress_based
    require_declared_outputs: true
    detect_repeated_tool_calls: true
    detect_repeated_navigation: true
    repeated_tool_call_threshold: 3
    on_no_progress: fail

  return_contract:
    type: json
    max_context_bytes: auto
    schema: {}

  artifact_spool:
    enabled: true
    path: ".openclaw-workflow/sealed"

Sealed command example

- id: normalize_manifest
  kind: sealed
  sealed:
    mode: command
    command:
      argv: ["node", "scripts/normalize-manifest.mjs", "--date", "{date}"]
    return_contract:
      type: json
      schema:
        type: object
        required: [status]
        properties:
          status:
            type: string
  outputs:
    - id: normalized_manifest
      validate: manifest_schema

Sealed worker example

- id: collect_jobs
  kind: sealed
  task: |
    Collect jobs and commit declared outputs.
  sealed:
    mode: tool_worker
    context_firewall:
      enabled: true
  outputs:
    - id: jobs_manifest

Capability boundary note

Sealed tool_worker steps with context firewall require adapter-enforced runtime capabilities. If the chosen adapter cannot enforce tool-result interception, transcript firewall, and artifact sink, the run fails before spawning the worker.

This prevents silent downgrade from sealed runtime enforcement to prompt-only behavior.

Plugin Steps (kind: plugin)

Plugin steps execute built-in workflow operations directly in the orchestrator (no spawned subagent session).

Rules:

• must declare kind: plugin
• must include uses: <operation_id>
• may include with: { ... } operation arguments
• cannot use for_each
• may still use depends_on, outputs, retry policy, and variable substitution

For semantic state plugin operations (workflow.state_publish, workflow.state_query, workflow.state_partition, workflow.state_report, etc.):

• authoring can define config at top-level state_*
• compiler normalizes compiled config so with.state_* is populated
• top-level state_* is retained on compiled steps for traceability
• if both top-level and with.state_* are present but differ, compilation fails

Built-in operation IDs:

• workflow.cache_json_document
• workflow.state_init
• workflow.redis_run_initializer
• workflow.state_publish
• workflow.state_claim
• workflow.state_reclaim_expired
• workflow.state_complete
• workflow.state_query
• workflow.state_patch_outputs
• workflow.state_partition
• workflow.state_report

workflow.cache_json_document

Reads a JSON file, commits it as a declared artifact output, and (when Redis is available) mirrors it into Redis.

with fields:

• required: source_path, json_key
• conditionally required: hash_key (required when Redis is configured)
• optional: allowed_hash_fields, ttl_seconds, base_dir, output_id

Example:

- id: cache_profile
  kind: plugin
  uses: workflow.cache_json_document
  with:
    source_path: data/profile-{date}.json
    json_key: cache:profile:{run_id}
    hash_key: cache:profile_hash:{run_id}
    allowed_hash_fields: [profile_id, status]
    output_id: profile_cache
  outputs:
    - id: profile_cache
      validate: profile_schema

workflow.state_init

Initializes run metadata/counters/stream-group idempotently, and commits an initialization artifact even when Redis is unavailable.

workflow.redis_run_initializer remains supported as a backward-compatible alias.

with fields:

• required: run_key
• optional: stream_key, stream_group (default workers), counter_keys, metadata, ttl_seconds, output_id

Example:

- id: init_run_state
  kind: plugin
  uses: workflow.state_init
  with:
    run_key: runs:{run_id}
    stream_key: events:{run_id}
    stream_group: workers
    counter_keys:
      processed:{run_id}: 0
      failed:{run_id}: 0
    metadata:
      workflow: "{workflow_name}"
      run_id: "{run_id}"
    output_id: run_config
  outputs:
    - id: run_config

Semantic state resources for explicit plugin steps

Use these top-level blocks when you want workflow YAML to describe what state exists while the plugin decides how it maps to Redis-backed views.

state:
  backend: auto
  collections:
    task_alerts:
      entity: alert
      item_key: alert_key
      default_queue: task_alerts_pending
      indexes: [route, status, submitted]
      views:
        document: true
        metadata_hash: true
        seen_index: true
        pending_queue: true
        event_stream: true
      counters:
        published: task_alerts_published
        completed: task_alerts_completed
        failed: task_alerts_failed
  queues:
    task_alerts_pending:
      collection: task_alerts
      batch_size: 25
      visibility_timeout_s: 900
  worker_groups:
    task_alert_classifier:
      queue: task_alerts_pending
      batch_size: 10
      lease_seconds: 900

Semantic resource notes:

• collections.<name> defines the entity model and keying rules.
• queues.<name> defines batching / pending-work semantics for a collection.
• worker_groups.<name> defines how claimers resolve a queue plus lease behavior.
• collections.<name>.indexes defines secondary index fields maintained as sets ({prefix}:set:{collection}:idx:{field}:{value}:{date}).

workflow.state_publish

Publishes items from a prior step artifact into a semantic collection and queue, then writes a summary artifact.

Use when:

• a worker step already produced a manifest artifact
• you want the orchestrator/plugin to materialize queue/state views
• you do not want subagents hand-writing Redis commands

state_publish fields:

• required: from_step, output
• recommended: collection
• optional: source (auto | exact | descendants), queue, select, item_key, summary_output

Example:

- id: publish_task_alert_state
  kind: plugin
  uses: workflow.state_publish
  state_publish:
    from_step: collect_task_alerts
    output: alerts_manifest
    collection: task_alerts
    queue: task_alerts_pending
    item_key: alert_key
    summary_output: state_publish_summary
  depends_on: [collect_task_alerts]
  outputs:
    - id: state_publish_summary

Behavior:

• reads the declared artifact from from_step / output
• in auto mode, resolves either the exact artifact (from_step.output) or descendant loop/drain artifacts (from_step:<n>:...)
• selects items from the artifact payload (default root item list)
• publishes documents / hashes / queue entries / stream events according to the collection config
• first-seen items increment published_count; previously-seen items increment updated_count
• queue enqueue remains idempotent (no duplicate pending entries for the same item key)
• increments configured counters when present
• commits a summary artifact for downstream auditing

Important:

• artifact-only fallback is only safe for non-queue projections. If the publish writes to a queue, Redis is required because there is no filesystem-backed queue consumer yet.

workflow.state_claim

Claims work from a semantic queue or worker group and writes a claim manifest artifact for downstream worker steps.

state_consume fields:

• required: one of queue or worker_group
• required: output
• optional: batch_size, lease_seconds

Example:

- id: claim_task_alert_batch
  kind: plugin
  uses: workflow.state_claim
  state_consume:
    worker_group: task_alert_classifier
    output: claim_manifest
  depends_on: [publish_task_alert_state]
  outputs:
    - id: claim_manifest

- id: classify_claimed_alerts
  depends_on: [claim_task_alert_batch]
  input:
    claim:
      from: claim_manifest
      inject_as: claim
      max_bytes: 32768
      require_lease: true
      expose_artifact_path: false
  task: |
    Process the engine-injected claim and classify each item.
  outputs:
    - id: classification_results

Behavior:

• resolves the queue from state_consume.queue or the declared worker group
• reclaims expired leases back to pending before new claims
• also reclaims orphaned processing entries that have no active lease record (for example, after a crash between queue move and lease bookkeeping)
• claims up to the configured batch size using atomic pending → processing movement
• writes active leases during claim; when Lua/eval is available this happens in the same Redis operation as the queue move
• appends claim events when event streams are enabled
• commits a manifest artifact containing flattened claimed items (plus item_key and lease) for downstream steps
• includes deterministic summary fields such as claimed_count, reclaimed_expired_count, and reclaimed_orphaned_count

Important:

• workflow.state_claim requires Redis. There is currently no filesystem-backed queue implementation, so artifact-only mode is intentionally rejected for queue claims.

Engine-injected claim context (input.claim)

Workers can consume claim manifests through engine-injected bounded context rather than reading artifact files/paths directly.

Preferred step syntax:

input:
  claim:
    from: claim_manifest
    from_step: claim_task_alert_batch   # optional; auto-resolved from immediate depends_on when omitted
    inject_as: claim                    # default: claim
    max_items: 50                       # optional; default: all claimed items
    max_bytes: 32768                    # optional; default: 32768
    include_fields: [item_key, lease, route, href]   # optional projection
    require_lease: true                 # default: true
    expose_artifact_path: false         # default: false

Backward-compatible alias:

input_context:
  from_claim: claim_manifest
  mode: injected

Runtime behavior:

• executor resolves the producer claim artifact before worker spawn
• injects a bounded JSON object into worker context (default key: claim)
• rejects invalid/unsafe configs (for example max_bytes <= 0, max_items < 0)
• blocks expose_artifact_path: true for agent worker steps
• supports both normal and sealed worker execution paths

Authoring drain behavior:

• drain-generated worker steps now default to injected claim input when they depend on the nested claim step
• generated worker prompt guidance is: process only engine-injected claim, do not read claim artifact paths/directories

workflow.state_reclaim_expired

Requeues expired leases — and orphaned processing entries without a matching lease record — without claiming new work.

Use when:

• you want an explicit recovery/repair step in the workflow graph
• you want lease cleanup to run on a schedule or before a specific worker wave

state_reclaim fields:

• required: one of queue or worker_group
• optional: output

Example:

- id: reclaim_task_alert_batch
  kind: plugin
  uses: workflow.state_reclaim_expired
  state_reclaim:
    worker_group: task_alert_classifier
    output: reclaim_summary
  outputs:
    - id: reclaim_summary

Behavior:

• scans the queue's processing list and active lease hash
• requeues expired active leases back to pending
• requeues orphaned processing entries that have no active lease record
• writes a recovery summary artifact with reclaimed_expired_count, reclaimed_orphaned_count, and reclaimed_count

workflow.state_complete

Marks claimed items as completed or failed based on a result artifact written by a downstream worker step.

state_complete fields:

• required: from_step, output
• required: one of collection, queue, or worker_group
• optional: select, item_key, status_field, summary_output, merge_document, merge_fields, indexes, require_rows, fail_on_skipped, fail_on_stale

Example:

- id: complete_task_alert_batch
  kind: plugin
  uses: workflow.state_complete
  state_complete:
    from_step: classify_claimed_alerts
    output: classification_results
    worker_group: task_alert_classifier
    collection: task_alerts
    select: $.items
    item_key: alert_key
    status_field: status
    merge_document: true
    require_rows: true
    fail_on_skipped: true
    fail_on_stale: true
    summary_output: state_complete_summary
  depends_on: [classify_claimed_alerts]
  outputs:
    - id: state_complete_summary

Behavior:

• reads result items from the upstream artifact
• verifies lease identity when lease metadata is present
• skips stale lease completions (records stale_count) rather than incorrectly completing newer claims
• removes matching active leases and processing-queue entries for accepted completions
• places items into semantic completed/failed membership sets
• optionally merges completion/result fields back into Redis document/hash state (merge_document / merge_fields)
• maintains configured secondary indexes during merge (collections.<name>.indexes plus per-step indexes)
• appends lifecycle events to the collection stream when configured
• increments completion/failure counters and writes a summary artifact
• supports strict safety gates:
  • require_rows: true fails completion when selection returns zero rows
  • fail_on_skipped (default true) fails when rows are skipped due to missing item keys
  • fail_on_stale (default true) fails when stale lease completions are detected

state_complete.route_queues — downstream queue routing

After each item is completed, workflow.state_complete can atomically enqueue the item key into one or more downstream semantic queues based on route, status, or field-match conditions.

Add a route_queues list to state_complete:

state_complete:
  from_step: classify
  output: classification_results
  worker_group: jobs_classifier
  collection: jobs
  route_queues:
    - queue: jobs_easy_apply        # target semantic queue name from workflow.state.queues
      when:
        route: easy_apply           # match on item field value
      lifecycle: queued             # optional lifecycle tag written into document
    - queue: jobs_needs_review
      when:
        status: needs_review

StateRouteQueueSpec fields:

• required: queue — semantic queue name (workflow.state.queues.<name>)
• optional: when — field/value predicate map; all conditions must match (AND)
• optional: lifecycle — string written to the document lifecycle field on enqueue
• optional: collection — override the collection (defaults to the enclosing state_complete collection)

The summary artifact output by state_complete includes routing statistics:

{
  "routed_count": 42,
  "routed_by_queue": { "jobs_easy_apply": 30, "jobs_needs_review": 12 },
  "route_duplicates": 3,
  "route_skipped": 0
}

• route_duplicates counts items that were already members of the target queued-set (no double-enqueue).
• route_skipped counts items where no route_queues rule matched.

workflow.state_query

Queries a semantic collection from Redis and writes bounded query results as an artifact.

state_query fields:

• required: collection, output
• optional: where, projection, limit, offset, summary_output

Example:

- id: query_ready_alerts
  kind: plugin
  uses: workflow.state_query
  state_query:
    collection: task_alerts
    where:
      all:
        status: ready
    projection: [item_key, status, route]
    limit: 500
    output: ready_alerts
    summary_output: state_query_summary
  outputs:
    - id: ready_alerts
    - id: state_query_summary

Behavior:

• uses collection secondary indexes for simple equality, all intersections, and any unions when possible
• falls back to collection seen-set scan + predicate matching when needed
• always re-checks matched documents with the full where predicate for correctness
• commits query output and optional summary artifact

workflow.state_patch_outputs

Merges rows from one or more artifacts into semantic Redis documents/hashes without exposing those rows to model context.

state_patch_outputs fields:

• required: collection, output
• required in practice: from_step (or plugin step dependency)
• optional: source (auto | exact | descendants), select, item_key, merge_fields, status_field, indexes, summary_output

Example:

- id: patch_classification_back
  kind: plugin
  uses: workflow.state_patch_outputs
  state_patch_outputs:
    from_step: classify_claimed_alerts
    output: classification_results
    collection: task_alerts
    item_key: alert_key
    merge_fields: [route, status, submitted]
    indexes: [route, status, submitted]
    summary_output: state_patch_outputs_summary
  outputs:
    - id: state_patch_outputs_summary

Behavior:

• reads matching artifacts from from_step using source-mode resolution (including colon-prefixed loop/drain descendants)
• merges selected fields into Redis document + hash records
• updates secondary indexes for merged fields and removes stale index memberships on value changes
• commits a summary artifact with patched/skipped counts

workflow.state_partition

Partitions collection items into named bounded outputs and can optionally enqueue each partition into a semantic queue.

state_partition fields:

• required: collection, partitions
• optional: projection, limit_per_partition, item_key, summary_output

Example:

- id: partition_alerts
  kind: plugin
  uses: workflow.state_partition
  state_partition:
    collection: task_alerts
    projection: [item_key, status, route]
    partitions:
      ready:
        where: { status: ready }
        output: alerts_ready
        queue: task_alerts_pending
      blocked:
        where: { status: blocked }
        output: alerts_blocked
    summary_output: state_partition_summary
  outputs:
    - id: alerts_ready
    - id: alerts_blocked
    - id: state_partition_summary

Behavior:

• resolves each partition independently via semantic query filters
• commits one output artifact per partition
• validates queue ownership (state.queues.<name>.collection) before enqueueing
• optionally enqueues each partitioned item and writes partition events to stream
• when partition.lifecycle is set, patches document state (lifecycle, queued_for, partition) to keep Redis state aligned with routing
• commits aggregate partition summary

workflow.state_report

Generates bounded final reporting artifacts directly from semantic Redis state.

state_report fields:

• required: json_output
• optional: collections, counters, include_samples, markdown_output

Example:

- id: final_state_report
  kind: plugin
  uses: workflow.state_report
  state_report:
    collections: [task_alerts]
    counters: [task_alerts_published, task_alerts_completed, task_alerts_failed]
    include_samples: 25
    json_output: final_report_json
    markdown_output: final_report_md
  outputs:
    - id: final_report_json
    - id: final_report_md

Behavior:

• reports seen/completed/failed totals by collection
• reports per-index value breakdowns when requested (or from collection defaults)
• optionally includes bounded sample items per collection
• optionally resolves configured counters
• emits JSON report and optional Markdown report artifacts

Explicit plugin flow vs. state_contract

There are now two complementary semantic patterns:

• state_contract: best when a normal worker step should produce outputs and the runtime should project state automatically after validation.
• workflow.state_publish / workflow.state_claim / workflow.state_complete: best when you want the workflow graph to model publish/claim/complete as explicit orchestration steps.

Both keep Redis details out of worker prompts and YAML-level imperative scripts.

Current limitation:

• state_contract and the explicit plugin-step state operations do not currently share the same key naming convention. state_contract projects keys using the contract entity (for example queue:alerts:pending), while explicit plugin steps key by collection/queue names. Until those namespaces are unified, do not mix both approaches for the same records if you need a single canonical queue/state view.

State Drain Controller (kind: state_drain)

Use state_drain when you want the orchestrator itself to act as a queue-drain scheduler/controller.

What it does:

• starts an iteration
• runs nested steps (which should include a workflow.state_claim plugin step)
• inspects the claim artifact (claimed_count, valid_count, or items.length)
• if claimed count is 0, treats the queue as empty for that iteration
• stops after max_empty_claims consecutive empty claims
• otherwise expands the next iteration and continues

drain fields:

• required: worker_group
• optional: max_empty_claims (default 1)
• optional: max_iterations (null/unset = no explicit cap)
• optional: max_active_iterations (default 1) — number of concurrent active drain iterations

Example:

- id: classifier_drain
  kind: state_drain
  name: Drain classifier queue
  depends_on: [publish_task_alert_state]
  drain:
    worker_group: task_alert_classifier
    max_empty_claims: 1
    max_iterations: 100
  steps:
    - id: claim
      kind: plugin
      uses: workflow.state_claim
      state_consume:
        # worker_group can be omitted here; controller injects drain.worker_group if missing
        output: claim_manifest
      outputs:
        - id: claim_manifest

    - id: classify
      depends_on: [claim]
      task: |
        Read claim_manifest and classify claimed items.
      outputs:
        - id: classification_results

    - id: complete
      kind: plugin
      uses: workflow.state_complete
      depends_on: [classify]
      state_complete:
        from_step: classify
        output: classification_results
        worker_group: task_alert_classifier
        collection: task_alerts
        require_rows: true
        fail_on_skipped: true
        fail_on_stale: true
        summary_output: state_complete_summary
      outputs:
        - id: state_complete_summary

Notes:

• state_drain is a scheduler/controller step, not a plugin operation ID.
• nested step instances are expanded dynamically as <drain_step_id>:<iteration>:<child_id>.
• controller keeps up to max_active_iterations iterations active concurrently.
• non-optional child failed/blocked statuses fail the controller.
• on empty claim, pending downstream children in that iteration are marked skipped.

Streaming Drain Mode

By default, state_drain uses drain_mode: batch — it stops after max_empty_claims consecutive empty iterations.

Set drain_mode: streaming to keep the drain alive while upstream producers are still running. The controller will idle-poll instead of immediately stopping on an empty claim, and will only close when stop conditions are met.

Additional drain fields for streaming mode:

• drain_mode: "batch" (default) | "streaming"
• idle_wait_seconds: seconds to wait between idle polls (default 10)
• max_idle_seconds: hard timeout in seconds; drain closes even if stop conditions are not met (default 600)
• stop_when.producers_done: list of step IDs — all must reach a terminal status (ok, failed, blocked, or skipped)
• stop_when.queues_empty: list of semantic queue names — all must have zero items in their pending list

Important: stop_when.producers_done step IDs are not treated as DAG dependencies of the drain step. They are checked at runtime inside the idle loop. If you also need the drain to wait for a producer to start before it runs, add that producer to depends_on explicitly.

Example — drain waits for a publisher step to finish before stopping:

- id: publisher
  name: Publish jobs to queue
  uses: plugin
  # ...

- id: jobs_drain
  kind: state_drain
  name: Drain jobs queue (streaming)
  depends_on: []          # drain can start immediately
  drain:
    worker_group: jobs_processor
    drain_mode: streaming
    idle_wait_seconds: 15
    max_idle_seconds: 1800
    stop_when:
      producers_done: [publisher]   # wait until publisher finishes
      queues_empty: [jobs_pending]  # and the queue is empty
  steps:
    - id: claim
      kind: plugin
      uses: workflow.state_claim
      state_consume:
        worker_group: jobs_processor
        output: claim_manifest
      outputs:
        - id: claim_manifest
    # ... worker and complete steps

workflow.external_landing_preflight

Safely probes external job application landing pages before a browser agent attempts to apply. The plugin reads a claim artifact, evaluates each item's URL, classifies page safety, and enqueues safe items into a verified downstream queue.

Plugin operation ID: workflow.external_landing_preflight

external_landing_preflight spec fields:

• required: claim_output — output ID from the upstream claim step
• required: output — artifact output ID for the preflight result
• required: collection — semantic collection name
• required: verified_queue — semantic queue name to enqueue safe items into
• optional: from_step — step to read the claim artifact from (defaults to current step)
• optional: max_items — cap on items to preflight per call (default: all claimed items)
• optional: max_redirects — redirect follow cap (default: 5)
• optional: timeout_ms — per-item probe timeout (default: 8000)
• optional: verified_lifecycle — lifecycle tag written to queued items
• optional: include_fields — item fields to carry forward into the output artifact
• optional: allowed_actions — probe actions permitted: navigate, read_dom_metadata, read_links, read_forms, read_buttons
• optional: blocked_actions — actions always blocked: submit_form, upload_file, download_file, execute_file, enter_credentials
• optional: safety — detection flags: require_domain_consistency, detect_downloads, detect_obfuscated_redirects, detect_login_or_verification, detect_assessment_or_screening, detect_unrelated_page
• optional: matching — URL/title match scoring weights and thresholds: title_weight, company_weight, url_weight, strong_match_threshold, ambiguous_threshold
• optional: decisions — classify decision codes into eligible, blocked, skipped, retryable lists

Output artifact shape:

{
  "status": "ok",
  "generated_at": "2025-01-01T00:00:00.000Z",
  "items": [
    {
      "job_id": "job_123",
      "item_key": "job_123",
      "lease": "...",
      "route": "easy_apply",
      "status": "eligible",
      "submitted": false,
      "retryable": false,
      "reason": "eligible",
      "landing_decision": "eligible",
      "safe_to_attempt": true,
      "entrypoint_url": "https://example.com/apply/123",
      "matched_job_url": "https://example.com/apply/123",
      "match_confidence": 1.0,
      "match_confidence_bucket": "strong",
      "external_preflight": {
        "final_url": "https://example.com/apply/123",
        "page_title": "Software Engineer",
        "risk_flags": []
      }
    }
  ],
  "rejected_items": [],
  "workflow_result": { "ok": true, "retryable": false, "blocked": false, "failed": false }
}

landing_decision values:

• eligible — page appears safe to attempt
• blocked — blocked by safety policy
• login_required — page redirected to login or auth
• download_risk — URL points to a downloadable file
• redirect_limit — followed too many redirects
• timeout — probe timed out
• unrelated_page — page content does not match job description
• skipped — item had no apply_url/job_url
• unknown — undetermined

Example usage in an authoring workflow:

- id: preflight_easy_apply
  kind: plugin
  uses: workflow.external_landing_preflight
  depends_on: [claim_easy_apply]
  external_landing_preflight:
    from_step: claim_easy_apply
    claim_output: claim_manifest
    output: preflight_results
    collection: jobs
    verified_queue: jobs_verified_easy_apply
    max_items: 5
    safety:
      require_domain_consistency: true
      detect_downloads: true
      detect_login_or_verification: true
    matching:
      strong_match_threshold: 0.8
      ambiguous_threshold: 0.5
  outputs:
    - id: preflight_results

Automatic Step Signaling (Prompt Injection)

When signaling is enabled for a step, the plugin injects a runtime protocol into the spawned step prompt so workflow authors do not need to embed signaling boilerplate in every task.

Injected guidance includes:

• periodic workflow_step_update progress updates
• final workflow_step_complete handoff request
• current run_id and step_id
• current attempt and handoff_token when available
• declared-output contracts derived from outputs[].validate and workflow.validators
• write_output commit instructions for declared outputs
• repair-and-retry behavior when completion is rejected due to invalid outputs

Default behavior:

• complete_when: handoff or complete_when: handoff_or_outputs → signaling: auto
• all other completion modes → signaling: off

You can override per-step:

- id: produce_manifest
  complete_when: handoff_or_outputs
  signaling: auto   # optional, auto by default for this complete_when
  task: |
    Build and validate manifest JSON outputs.

- id: custom_controller
  complete_when: handoff
  signaling: off    # disable auto-injection if you need fully custom behavior
  task: |
    Run custom orchestration logic.

Migration note:

• Existing workflows that already include manual “Workflow signaling protocol” text in task will continue to work.
• You can safely remove most of that repeated text and rely on signaling: auto for cleaner workflow files.

Semantic State Contracts (runtime-projected)

Use semantic contracts when a step output should be interpreted as operational state (for example, a pending queue of alerts) without exposing Redis commands in YAML or prompts.

How it works:

1. Worker writes declared outputs (write_output / normal output contract path).
2. Orchestrator validates outputs.
3. If state_contract is declared, runtime projects the validated artifact to state views.
4. If Redis is unavailable and policy is artifact_only, outputs still pass and remain usable.

Example:

state:
  backend: auto
  fallback: filesystem
  materialize_outputs: on_demand
  redis:
    provider: auto
    tool_prefix: MCP_DOCKER
  contracts:
    task_alert_collection:
      kind: collection
      entity: alert
      item_key: alert_key
      source_output: alerts_manifest
      raw_output: alerts_raw
      metadata_output: alerts_metadata
      summary_output: alerts_summary
      lifecycle: pending
      dedupe:
        by: [saved_search_id, href, query]
      state_views:
        document: true
        metadata_hash: true
        seen_index: true
        pending_queue: true
        event_stream: true
      counters:
        collected: alerts_collected
        rejected: alerts_rejected
      on_no_redis: artifact_only

steps:
  - id: collect_task_alerts
    task: Collect task alert notifications.
    state_contract: task_alert_collection
    outputs:
      - id: alerts_raw
      - id: alerts_metadata
      - id: alerts_manifest
      - id: alerts_summary

Notes:

• state_contract is semantic metadata, not an imperative Redis script.
• Worker prompts are isolated to declared inputs/outputs and avoid backend implementation details.
• Current runtime projector supports kind: collection and safely scalarizes hash fields.

Automatic Declared Output Handling

If a step has declared outputs, the plugin now injects a second runtime contract automatically. You do not need any new YAML fields for this behavior.

What the injected contract tells the worker:

• declared outputs are owned by the workflow plugin
• declared output files must be committed with write_output
• the prompt includes the resolved validator contract, not just a validator name
• when a validator has a useful schema shape, the prompt includes the expected object/array structure and examples

That means a step like this:

- id: build_manifest
  complete_when: outputs
  task: Build today's alert manifest.
  outputs:
    - path: data/alerts-execution-manifest-{date}.json
      validate: alert_manifest_array

causes the runtime prompt to include guidance such as:

• exact declared output path
• validator ID (alert_manifest_array)
• resolved schema shape (for example, JSON array with item fields)
• semantic rules (pass_when, retry_when, block_when, fail_when, unknown_policy)
• an example item or blocked artifact when the validator shape makes that useful

Safe Output Commit and Provenance

The new write_output tool is the authoritative path for declared outputs.

For declared outputs it performs all of the following:

• resolves the declared output path and confirms it belongs to the current step
• resolves the validator from the existing workflow.validators map
• validates the candidate value with the same validator engine used by output gating
• writes through a same-directory temp file
• re-validates the staged file from disk
• atomically renames the staged file into place
• records provenance in run state, including run_id, step_id, attempt, path, bytes, decision, and SHA-256

Important consequences:

• malformed JSON from an older attempt no longer poisons a still-running retry forever; the worker can repair it and commit a fresh artifact atomically
• manual/direct writes to declared output files are still visible to final validation, but they do not cause early completion while the session is still running
• early pass, blocked, or retry output decisions now require matching current-attempt provenance
• once the session itself ends, the orchestrator still performs the normal final output validation before accepting completion

This keeps YAML stable while making runtime behavior much stricter and safer.

reuse_outputs fields

Field	Type	Required	Default	Description
enabled	boolean	❌	false	Enables pre-launch cache adoption checks for this step.
when	string	❌	—	CEL expression to decide if cache reuse is allowed (permission gate).
require	string	❌	"declared_outputs"	Currently must be "declared_outputs".
accept_decisions	string[]	❌	["pass"]	Which merged validator decisions are adoptable (e.g., include "blocked" if desired).
require_signature	boolean	❌	true	Requires cache manifest/signature match before adoption.
legacy_unsigned_cache	string	❌	"stale"	Policy for old artifacts without signatures: "stale" or "allow_if_valid".
freshness.include	string[]	❌	all supported	Signature components to include: output_contract_version, step_task, validators, schemas, selected_config, input_signature.
on_hit.reason	string	❌	"cache_hit"	Audit reason persisted when cache is adopted.
on_invalid	string	❌	"run_step"	Behavior when cache is invalid/stale: "run_step" or "fail_step".

Retry Policy Notes: retry_on and retry_except use Failure Kinds. Available kinds: timeout, timeout_stop_confirmed, timeout_stop_unconfirmed, missing_file, schema, fail_when, parse, other.

Example Pattern: Conditional Execution Use skip_if_empty to avoid launching expensive agents when there is no data to process:

- id: generate_report
  name: "Generate Daily Report"
  depends_on: [collect_data]
  skip_if_empty: "data/daily_metrics.json" # Skip if no metrics were collected
  task: "Analyze metrics in data/daily_metrics.json and write a report..."

---

Variable Substitution

The following {variable} tokens are substituted in task and outputs fields at run time:

Variable	Example value	Description
{date}	2026-03-09	Current date as YYYY-MM-DD (Workflow timezone)
{datetime}	2026-03-09T08:20:00	Current datetime as ISO-ish string (Workflow timezone)
{utc_date}	2026-03-09	Current date as YYYY-MM-DD (UTC)
{utc_datetime}	2026-03-09T08:20:00.000Z	Current datetime as ISO 8601 (UTC)
{run_id}	seo-pipeline-20260309T082000	The unique run identifier
{workflow_name}	SEO Daily Pipeline	The name of the workflow
{workflow_run_id}	seo-pipeline-20260309T082000	The unique run identifier
{run_state_path}	/home/user/.openclaw/workflow-runs/seo-pipeline-20260309T082000.json	Path to the run state JSON file
{item}	Song-1.mp3	Current loop iteration value (only available inside for_each steps)
{config.X}	my-custom-value	Value of variable X from the top-level config block
{env.X}	/home/user	Value of environment variable X (for example {env.HOME})
\{variable}	{date}	Literal text (escaped). Prevents substitution.

Unknown {variables} are typically left as-is, except in for_each path templates where they cause an immediate error.

Example:

task: "Write audit to data/seo/{date}/report.json for run {run_id}"
outputs:
  - "data/seo/{date}/report.json"

---

Tools Reference

workflow_run

Start a workflow execution.

This is registered as an optional tool because it starts background agent work and writes run state. Enable optional tools in the OpenClaw tool UI/config when you want agents to launch workflows.

Input:

{
  "name": "seo-pipeline",
  "dry_run": false,
  "resume": false
}

Parameter	Type	Required	Description
name	string	✅	Workflow file stem (e.g. "seo-pipeline" for seo-pipeline.yml)
dry_run	boolean	❌	Validate and show execution plan without running. Default: false
resume	boolean	❌	Skip steps that already completed in the last run. Default: false

Response (normal run):

{
  "run_id": "seo-pipeline-20260309T082000",
  "workflow": "SEO Daily Pipeline",
  "status": "running",
  "total_steps": 3,
  "steps": {
    "tech-auditor": { "status": "pending", "depends_on": [] },
    "content-creator": { "status": "pending", "depends_on": ["tech-auditor"] },
    "standup": { "status": "pending", "depends_on": ["tech-auditor", "content-creator"] }
  },
  "message": "Workflow \"SEO Daily Pipeline\" started. Use workflow_status to track progress."
}

Response (dry run):

{
  "dry_run": true,
  "run_id": "seo-pipeline-20260309T082000",
  "total_steps": 3,
  "execution_waves": [
    [{ "id": "tech-auditor", "timeout_s": 420, "retry": 0, "optional": false }],
    [{ "id": "content-creator", "timeout_s": 600, "retry": 1, "optional": false }],
    [{ "id": "standup", "timeout_s": 300, "retry": 0, "optional": true }]
  ],
  "estimated_min_duration_s": 1320
}

---

workflow_status

Check the status of a run.

Input (by run_id):

{ "run_id": "seo-pipeline-20260309T082000" }

Input (by name — returns most recent):

{ "name": "seo-pipeline" }

Response:

{
  "run_id": "seo-pipeline-20260309T082000",
  "workflow": "SEO Daily Pipeline",
  "status": "running",
  "started_at": "2026-03-09T08:20:00.000Z",
  "completed_at": null,
  "elapsed_s": 210,
  "steps_ok": 1,
  "steps_failed": 0,
  "steps_total": 3,
  "steps": {
    "tech-auditor": {
      "status": "ok",
      "attempts": 1,
      "duration_s": 195,
      "error": null,
      "started_at": "2026-03-09T08:20:00.000Z",
      "completed_at": "2026-03-09T08:23:15.000Z"
    },
    "content-creator": {
      "status": "running",
      "attempts": 1,
      "duration_s": null,
      "error": null
    },
    "standup": {
      "status": "pending",
      "attempts": 0,
      "duration_s": null,
      "error": null
    }
  }
}

---

workflow_list

List all available workflows and their last run status.

Input: (none required)

Response:

{
  "workflows_dir": "/home/user/.openclaw/workflows",
  "count": 3,
  "workflows": [
    {
      "name": "data-pipeline",
      "display_name": "Data ETL Pipeline",
      "description": "Extract, Transform, Load pipeline...",
      "file": "/home/user/.openclaw/workflows/data-pipeline.yml",
      "last_run": {
        "run_id": "data-etl-pipeline-20260308T090000",
        "status": "ok",
        "started_at": "2026-03-08T09:00:00.000Z",
        "completed_at": "2026-03-08T09:14:22.000Z"
      }
    },
    {
      "name": "seo-pipeline",
      "display_name": "SEO Daily Pipeline",
      "description": "Daily SEO audit, content creation...",
      "file": "/home/user/.openclaw/workflows/seo-pipeline.yml",
      "last_run": null
    }
  ]
}

---

workflow_cancel

Cancel a running workflow. marks the run cancelled, prevents new steps from launching, and attempts to abort active worker sessions using the adapter cancellation path. Abort confirmation depends on the active OpenClaw runtime surface.

This is registered as an optional tool because it modifies persisted run state.

Input:

{ "run_id": "seo-pipeline-20260309T082000" }

Response:

{
  "run_id": "seo-pipeline-20260309T082000",
  "status": "cancelled",
  "running_steps": 1,
  "abort_requested": 1,
  "abort_failed": 0,
  "results": [
    {
      "step_id": "content-creator",
      "requested": true,
      "confirmed": false,
      "method": "gateway.chat.abort"
    }
  ]
}

---

workflow_step_update

Non-authoritative observability update from a running worker/step. This updates progress metadata only; it does not satisfy dependencies or complete the step.

Input:

{
  "run_id": "seo-pipeline-20260309T082000",
  "step_id": "content-creator",
  "status": "progress",
  "message": "Collected 12/30 items",
  "counters": { "processed": 12 }
}

---

workflow_step_complete

Authoritative handoff request from a running worker/step. The orchestrator still validates the declared output contract (and cache freshness signature when relevant) before accepting completion.

Input:

{
  "run_id": "seo-pipeline-20260309T082000",
  "step_id": "content-creator",
  "reason": "generated",
  "message": "Outputs written and ready",
  "attempt": 1,
  "handoff_token": "..."
}

If validation fails, the response returns structured details (missing/invalid outputs) so the worker can repair and continue.

write_output

Authoritative declared-output writer for running workers. Use this for any file listed under the step's outputs contract.

Input:

{
  "run_id": "seo-pipeline-20260309T082000",
  "step_id": "content-creator",
  "path": "data/seo-state/cc-manifest-2026-03-09.json",
  "data": [{ "slug": "post-1", "status": "ready" }]
}

You may provide either:

• data: structured JSON value to serialize
• text: raw text content

Migration note:

• write_output accepts either path (legacy) or output_id (preferred).
• For new workflows, prefer output_id to keep contracts path-independent.

---

Artifact-Backed Declared Outputs

Outputs can be declared with a logical id instead of (or in addition to) a filesystem path. Artifact-backed outputs are stored in the run artifact store and can be read, listed, and materialized via the read_output, list_outputs, and materialize_output tools.

Declaring logical outputs in YAML

name: My Pipeline
state:
  backend: filesystem          # filesystem | redis | auto | dual
  materialize_outputs: on_demand   # never | on_demand | always
  redis:
    provider: auto             # auto | mcp | native
    tool_prefix: MCP_DOCKER
steps:
  - id: build_report
    task: "Build and commit the daily report."
    outputs:
      # Path-only (legacy, unchanged):
      - path: data/report-{date}.json
        validate: report_schema

      # ID-only (artifact-backed, no filesystem path):
      - id: daily-summary
        validate: summary_schema

      # Both (artifact-backed + auto-materialized to path):
      - id: alert-manifest
        path: data/alerts-{date}.json
        materialize:
          mode: always

When a step output has only an id, workers use write_output with output_id instead of path:

{
  "run_id": "my-pipeline-20260503T090000",
  "step_id": "build_report",
  "output_id": "daily-summary",
  "data": { "items": 42, "status": "ok" }
}

The artifact is stored in {runsDir}/.artifacts/{runId}/{stepId}/{outputId}.json and is accessible via read_output without materializing to disk.

Behavior:

• only allows writes to outputs declared for the current step
• reuses the existing validator layer; there are no extra YAML schema keys for writers
• rejects non-committable results such as validator fail
• allows committable non-pass results such as blocked or retry when that is what the validator contract declares
• persists provenance used by running-step early completion checks

If a worker manually writes a declared output instead of using write_output, the orchestrator may still validate it at final completion, but it will not trust that file for early completion while the worker session is still active.

read_output

Read one declared artifact by run_id, step_id, and output_id.

Parameter	Type	Required	Description
run_id	string	✅	Workflow run ID
step_id	string	✅	Producing step ID
output_id	string	✅	Declared output id
fields	string[]	❌	Restrict which keys are returned from the artifact (projection)
limit	number	❌	For array artifacts, return only the first N items

list_outputs

List committed declared artifacts for a run.

Parameter	Type	Required	Description
run_id	string	✅	Workflow run ID
step_id	string	❌	Filter to a specific step

materialize_output

Materialize a stored artifact to the filesystem on demand.

Parameter	Type	Required	Description
run_id	string	✅	Workflow run ID
step_id	string	✅	Producing step ID
output_id	string	✅	Declared output id
path	string	❌	Target filesystem path (overrides the output's declared materialize.path)

workflow_state_get

Debug/admin tool that returns raw run state including backend resolution metadata.

Parameter	Type	Required	Description
run_id	string	✅	Workflow run ID
include_steps	boolean	❌	Include full per-step state (default true). Set false for a compact summary.

---

Cache Reuse and Contract Freshness

Cache adoption is a first-class orchestration feature and follows this order:

1. Evaluate reuse_outputs.when.
2. Validate declared outputs using the same validator engine as normal completion.
3. Compare cached artifact signature with the current contract signature.
4. Adopt only if decision is accepted and signature is fresh.

This distinguishes:

• invalid cache: fails current validators.
• stale cache: passes structure, but signature differs (task/validator/schema/config/input/contract version changed).

Cache manifests are stored under baseDir/.openclaw-workflow-cache/ and include producer run ID and signature metadata for auditability.

---

State File Format

Each workflow run writes state to {runsDir}/{run_id}.json:

{
  "run_id": "seo-pipeline-20260309T082000",
  "workflow": "SEO Daily Pipeline",
  "status": "ok",
  "started_at": "2026-03-09T08:20:00.000Z",
  "completed_at": "2026-03-09T08:47:12.000Z",
  "steps": {
    "tech-auditor": {
      "status": "ok",
      "started_at": "2026-03-09T08:20:00.000Z",
      "completed_at": "2026-03-09T08:23:15.000Z",
      "duration_ms": 195000,
      "session_key": "agent:main:subagent:abc123",
      "handoff_token": "seo-pipeline-20260309T082000:tech-auditor:attempt:1",
      "output_check": {
        "passed": true,
        "missing_files": [],
        "checked_files": ["/home/user/project/data/seo-state/ta-handoff-2026-03-09.json"]
      },
      "cache": {
        "hit": true,
        "adopted": true,
        "reason": "cache_hit",
        "current_contract_signature": "sha256:..."
      },
      "handoff": {
        "requested_at": "2026-03-09T08:23:12.000Z",
        "completed_at": "2026-03-09T08:23:15.000Z",
        "reason": "generated"
      },
      "output_writes": {
        "data/seo-state/ta-handoff-2026-03-09.json": {
          "path": "data/seo-state/ta-handoff-2026-03-09.json",
          "abs_path": "/home/user/project/data/seo-state/ta-handoff-2026-03-09.json",
          "decision": "pass",
          "run_id": "seo-pipeline-20260309T082000",
          "step_id": "tech-auditor",
          "attempt": 1,
          "bytes": 824,
          "sha256": "sha256:...",
          "committed_at": "2026-03-09T08:23:11.000Z"
        }
      },
      "error": null,
      "attempts": 1
    }
  }
}

Run status values: pending | running | ok | failed | blocked | cancelled

Step status values: pending | running | ok | failed | blocked | skipped

• skipped: Step was never run because a non-optional dependency failed
• failed: Step ran but failed (either session error or output gate failed)
• ok: Step ran successfully and output gate passed (or no outputs defined)

output_writes is internal provenance recorded by write_output. It is used to verify that early output-based completion came from the current attempt rather than a stale artifact or a direct manual file write.

---

Notifications

When notifyChannel is configured, the plugin sends messages to that channel after each step:

✅ Technical Auditor complete (195s)
✅ Content Creator complete (462s)
✅ Standup Synthesis complete (88s)
🏁 Pipeline "SEO Daily Pipeline" complete — 3/3 steps passed

On failure:

❌ Content Creator failed — retrying (attempt 2/2)
❌ Content Creator failed after 2 attempt(s): Output gate failed — missing: data/seo-state/cc-memo-2026-03-09.md
⚠️  Standup Synthesis failed (optional — continuing pipeline)
💥 Pipeline "SEO Daily Pipeline" failed — 1 step(s) failed, 2/3 passed

---

Execution Model

Dependency Graph

Steps execute based on their depends_on graph. Steps with no dependencies (or all dependencies satisfied) are ready and launch immediately, up to the concurrency limit.

Execution Waves Example

For this workflow:

A ──┐
    ├──→ C ──→ D
B ──┘

• Wave 1: A and B run in parallel
• Wave 2: C runs after both A and B finish
• Wave 3: D runs after C finishes

Cascade Skip

When a non-optional step fails, all steps that depend on it (directly or transitively) are marked skipped. This prevents false failures and makes the status clear: the step didn't fail, it was never attempted.

Loop Execution (for_each)

Workflows can iterate over a list of items using the for_each field.

How it works: The engine resolves the list based on the format of the for_each value:

1. Whole-Token References (e.g., {songs}):
   • First, it looks for the key in the current context.
   • If not found or not an array, it falls back to looking for a file named songs.json in the workspace.
2. Path Templates (e.g., manifest-{date}.json):
   • Variables are substituted strictly. If a variable (like {date}) is missing or invalid, the workflow fails immediately.
   • The resulting path is then resolved as a file.
3. Explicit Paths (e.g., songs.txt):
   • Resolved directly as a file.
4. Artifact References (e.g., { from_step: build_alert_execution_manifest, output: alerts_execution_manifest }):

• Reads the declared artifact directly from the run artifact store.

• Supports list payloads (data array) and single payloads (wrapped as one-item list).

• If the artifact is missing, loop expansion fails the loop step (failed), including optional loops.

• Expansion: A loop step is expanded into multiple unique step instances, one for each item in the list. An instance ID follows the pattern loop_id:index:inner_step_id.

• Dynamic Tasks: Use the {item} variable in task or outputs fields to refer to the current iteration's value.

• Dependency Resolution: If a step depends on a loop step, it will wait for all instances of the last step in that loop to complete before starting.

• List Parsing: The loop resolves the for_each value using a parser:

  • json (default/auto for .json): Parses a JSON array.
  • csv (auto for .csv): Splits content by commas.
  • newline (auto for .txt): Treats each line as a separate item.

• Example:

  steps:
    - id: find_songs
      name: "Find Songs"
      task: "Find today's liked songs and write them to songs.txt (one per line)"
      outputs: ["songs.txt"]

    - id: process_songs
      name: "Process Songs"
      depends_on: [find_songs]
      for_each: "songs.txt"
      parser: "newline"
      steps:
        - id: transcribe
          task: "Transcribe {item}..."

• Artifact-backed example:

  - id: process_alerts
    depends_on: [build_alert_execution_manifest]
    for_each:
      from_step: build_alert_execution_manifest
      output: alerts_execution_manifest
      parser: json
    steps:
      - id: notify
        task: "Send notification for {item.alert_key}"

• Example with Validation: Use item_schema to ensure the resolved list contains the expected data before expanding the loop:

  - id: process_alerts
    for_each: "data/alerts/alerts-execution-manifest-{date}.json"
    parser: "json"
    item_schema:
      type: object
      required: [alert_key]
      properties:
        alert_key:
          type: string
          pattern: "^alert_[a-z0-9_:-]+$"
    steps:
      - id: notify
        task: "Send notification for {item.alert_key}"

Resume

workflow_run({ name: "...", resume: true }) loads the most recent run, finds all steps with status: "ok", marks them as already-completed in the new run, and only executes the rest. Use this to recover from partial failures without re-doing expensive work.

---

Examples

SEO Pipeline (examples/seo-pipeline.yml)

Three sequential agents: Technical Auditor → Content Creator → Standup Synthesis. The Content Creator only runs if the Auditor wrote its handoff file. Standup is optional.

Deploy Pipeline (examples/deploy-pipeline.yml)

Four-stage gate: test → build → deploy → smoke-test. Uses concurrency: 1 to enforce strict sequencing. Deploy has retry: 1 for flaky network situations.

Data ETL Pipeline (examples/data-pipeline.yml)

Parallel fetch (primary + reference), then validate, transform, load, report. Demonstrates parallel steps fanning in to a single gate step, with the optional reporting stage at the end.

Music Processing Pipeline (examples/music-pipeline.yml)

Iterates over a list of audio files. For each file, it transcribes the audio and then generates a summary. Demonstrates loop expansion and the use of {item}.

Concurrency Demo (examples/concurrency-demo.yml)

Demonstrates how to use per-step concurrency limits to avoid rate-limiting on specific tasks while maintaining high global parallelism.

---

Development & Testing

npm install
npm run typecheck
npm run build
npm test
npm run check

Tests use Node.js built-in node:test and mock step runners. They do not require a real OpenClaw CLI install unless you are doing the optional local plugin install smoke test.

---

Operations and Security Notes

• Workflows cause agents to perform real work. Review workflow YAML/JSON before enabling workflow_run.
• Relative output paths are resolved under baseDir; set it to the workspace you expect agents to write into.
• Each step can set its own model and timeout; otherwise the plugin-level sessionModel and default timeout are used.
• If no stable native session runtime exists in the plugin API, CliAdapter falls back to the openclaw CLI and requires it in PATH.
• The CLI fallback uses argument arrays and preserves the Windows openclaw.ps1 wrapper case via PowerShell -File; workflow prompts are not shell-interpolated.

---

Maintainer Notes

Assumptions about OpenClaw internals

1. Plugin API shape: The entrypoint uses definePluginEntry from openclaw/plugin-sdk/plugin-entry and registers tools from register(api).

2. Native sessions: src/step-runner.ts prefers the modern api.runtime.subagent API (via RuntimeSubagentAdapter), with fallbacks to a legacy api.sessions surface and finally the OpenClaw CLI.

3. Notifications: The plugin uses api.notifications.send if available and otherwise writes progress through api.logger.

What OpenClaw should expose for full functionality

The plugin is designed to use the api.runtime.subagent surface for isolated background runs:

interface PluginApi {
  // Already present:
  registerTool(tool: ToolDefinition): void;
  pluginConfig: Record<string, unknown>;

  // Preferred surface:
  runtime: {
    subagent: {
      run(args: {
        sessionKey: string;
        message: string;
        provider?: string;
        model?: string;
        deliver: boolean
      }): Promise<{ runId: string }>;
      waitForRun(args: {
        runId: string;
        timeoutMs: number
      }): Promise<{ status: string; logs?: string; error?: string }>;
    };
  };
}

Files created

File	Purpose
src/index.ts	Plugin entry: registers workflow tools (workflow_run, workflow_status, workflow_list, workflow_cancel, workflow_step_update, workflow_step_complete)
src/config.ts	Plugin configuration normalization
src/workflow-loader.ts	YAML/JSON parsing, validation, cycle detection
src/workflow-executor.ts	Core execution engine: scheduling, deps, retry, resume, dry run
src/workflow-state.ts	Atomic state file R/W, run listing
src/state-artifact-stores.ts	Filesystem-backed WorkflowStateStore / WorkflowArtifactStore implementations + resolveStateBackend() resolver
src/state-contract-projector.ts	Semantic state contract projector that maps validated artifacts to runtime Redis/state views
src/step-runner.ts	Session lifecycle: spawn, poll, output check. Includes MockAdapter
src/output-checker.ts	File existence validation for output gates
src/output-validator.ts	Advanced output content validation
src/sealed-policy.ts	Sealed-mode policy normalization and defaults
src/sealed-spool.ts	Sealed data-plane spooling and compact envelope helpers
src/sealed-command-runner.ts	kind: sealed command-mode bounded execution
src/sealed-step-runner.ts	Sealed step dispatcher (command vs worker paths)
src/return-contract.ts	AJV-based validation for sealed control-plane returns
src/step-contract.ts	Shared contract validation, cache signature freshness, and cache manifest I/O
src/variable-substitution.ts	{date}, {datetime}, {utc_date}, {utc_datetime}, {run_id} substitution
src/list-resolver.ts	Resolves for_each sources (JSON, CSV, Newline)
src/template-schema-validator.ts	Validates variable templates in workflow definitions
src/tool-schemas.ts	Tool parameter definitions for OpenClaw SDK
src/types.ts	Shared TypeScript interfaces and types
openclaw.plugin.json	Plugin manifest + config schema
package.json	Package metadata
tests/*.test.js	Full test suite (Node built-in test runner)
tests/fixtures/*.yml	Fixture workflows for tests
examples/*.yml	SEO, deploy, and ETL example pipelines

---

Contributing

1. Fork the openclaw/openclaw repository
2. Copy this plugin to plugins/openclaw-workflow/
3. Run npm install && npm run check to verify tests pass
4. Submit a PR with the title: feat: add openclaw-workflow orchestration plugin

Please include test coverage for any new features or bug fixes.
