OpenFaceFX

Open-source lip-sync in the spirit of FaceFX: voice recording + transcript → animation curves that drive a character's face.

▶ Live demo — no install, regenerated from the current pipeline on every push. Read the docs →

The one-command quickstart, rendered from docs/quickstart.tape by VHS in CI on every push — recorded as code, so it can't drift from the real CLI. Open the live previewer →

Install

git clone https://github.com/OpenFaceFX/OpenFaceFX && cd OpenFaceFX
pip install -e .              # numpy is the only runtime dependency

(pip install openfacefx from PyPI is coming — the release automation is in place pending the registry setup, #24.)

Quick start

No models, no downloads — approximate lip-sync from text + a WAV's duration:

python -m openfacefx naive --text "hello world" --wav examples/voice.wav -o track.json

wrote track.json: 7 channels, 93 keyframes, 1.60s

track.json is the openfacefx.track format: sparse [time, value] keyframes per viseme channel, weights in [0, 1]. The real output begins:

{
  "format": "openfacefx.track",
  "version": 1,
  "fps": 60.0,
  "duration": 1.6,
  "viseme_set": [
    "sil",
    "PP",
    "FF",
    "TH",
    "DD",
    "kk",
    "CH",
    "SS",
    "nn",
    "RR",
    "aa",
    "E",
    "I",
    "O",
    "U"
  ],
  "channels": [
    {
      "name": "sil",
      "keys": [
        [
          0.0,
          0.6196
        ],

The first 30 lines of the actual file (7 channels, 93 keyframes in full). A reference reader is ~15 lines — see docs/COMPATIBILITY.md.

The 15 visemes

15 targets from the Oculus/Meta LipSync convention — a well-documented, IP-free set most character rigs already expose blendshapes for. Each mouth shape below is drawn by the same schematic articulator the live previewer animates, rendered at full weight (regenerate with python tools/render_viseme_gallery.py):

Viseme	Shape	Phonemes	Mouth
sil		—	neutral / mouth at rest
PP		B, M, P	lips pressed shut
FF		F, V	lower lip to upper teeth
TH		DH, TH	tongue between the teeth
DD		D, L, T	tongue to the alveolar ridge
kk		G, HH, K	back of tongue raised
CH		CH, JH, SH, ZH	rounded, protruded
SS		S, Z	narrow, teeth close
nn		N, NG	nasal, tongue up
RR		ER, R	retroflex / lightly rounded
aa		AA, AE, AH, AY	open jaw
E		EH, EY, IH	mid-front spread
I		IY, Y	wide spread
O		AO, AW, OW, OY	rounded and open
U		UH, UW, W	tight lip rounding

To retarget to a different rig (Apple ARKit's 52 blendshapes, a Preston-Blair 12-shape set, …), edit PHONEME_TO_VISEME and VISEMES in visemes.py — nothing else changes.

What it is

FaceFX-style tools are really four subsystems chained together. Only the first (acoustic alignment) needs a heavy model — and excellent open-source aligners already exist. So OpenFaceFX wraps the aligner instead of reinventing it, and fully owns the other three stages:

1. Alignment — time-stamped phonemes from Montreal Forced Aligner (parser included), or a dependency-free naive aligner for instant prototyping.
2. Phoneme → viseme — the widely-adopted Oculus/Meta 15-viseme convention.
3. Coarticulation — Cohen–Massaro dominance blending, so mouth shapes flow into each other instead of switching.
4. Keyframe reduction — Ramer–Douglas–Peucker thinning into sparse, engine-friendly curves.

Every seam is a tiny data contract (PhonemeSegment in, FaceTrack out), so any stage can be swapped without touching the rest.

More ways to generate

Accurate lip-sync from a Montreal Forced Aligner result:

# 1. run MFA (separately) to get voice.TextGrid, then:
python -m openfacefx mfa --textgrid voice.TextGrid -o track.json

Straight from a TTS engine's own timing — skip the aligner (espeak/MBROLA .pho, Piper, or Cartesia phonemes; Azure or Polly visemes; details and capture scripts in docs/timing.md):

python -m openfacefx from-timing --file visemes.json --format azure -o track.json

Or pin the naive aligner at known word/segment boundaries — subtitle cue times or TTS word timestamps (SRT, Azure/ElevenLabs/Kokoro/Google) — for much better sync with no models (SRT supplies its own transcript; the rest take --text):

python -m openfacefx naive --anchors cues.srt --anchors-format srt --wav voice.wav -o track.json

No transcript at all? Drive the mouth straight from audio loudness — an amplitude fallback in the spirit of SALSA/Moho/Live2D (energy, not viseme detection; good for barks, crowds, or a quick pass when all you have is a WAV):

python -m openfacefx energy --wav examples/voice.wav -o track.json

Straight to a Unity AnimationClip, or remapped onto another rig:

python -m openfacefx naive --text "..." --wav voice.wav -o clip.anim   # viseme_* curves
python -m openfacefx naive --text "..." --wav voice.wav -o clip.anim --anim-naming vrchat
python -m openfacefx mfa --textgrid voice.TextGrid -o track.json --retarget arkit

Or a stepped cue list for the indie 2D ecosystem — Rhubarb TSV/XML/JSON, Moho/OpenToonz .dat (Preston-Blair drawing names), Papagayo .pgo — flattened to the dominant mouth shape per interval (extension picks the format; .json stays the native track, so ask for the Rhubarb JSON explicitly):

python -m openfacefx naive --text "..." --wav voice.wav -o cues.tsv          # Rhubarb TSV
python -m openfacefx mfa --textgrid voice.TextGrid -o mouth.dat              # Moho/OpenToonz
python -m openfacefx mfa --textgrid voice.TextGrid -o cues.json --cue-format json-cues

Or bake into a VTuber/game engine's own animation asset — a Live2D Cubism motion3.json (a single mouth-open parameter curve by default, or per-vowel ParamA/I/U/E/O via --live2d-params, or read the target from a model's model3.json LipSync group) and a Godot 4 AnimationPlayer resource (.tres, one blendshape value track per viseme, --godot-node/--godot-naming):

python -m openfacefx naive --text "..." --wav voice.wav -o mouth.motion3.json  # Live2D Cubism
python -m openfacefx mfa --textgrid voice.TextGrid -o lipsync.tres            # Godot 4

Whole dialogue trees at once, with an OOV/confidence QA report and incremental re-runs:

python -m openfacefx batch --dir voice/ --out tracks/ --recurse --modified-only --jobs 8

Weighted many-to-many phoneme mapping and coarticulation timing are data/parameters, not code — see examples/mappings/ and CoartParams. JALI-style artistic dials tune articulation strength without retiming: --intensity (master, <1 mumbles, >1 hyper-articulates) and repeatable --gain class=value (e.g. --gain tongue=0.6 --gain jaw=1.2); all 1.0 is a byte-identical no-op.

Library use:

from openfacefx import generate_naive, load_mfa_textgrid, generate_from_alignment, write_json

track = generate_naive("the quick brown fox", duration=1.8)      # quick path
# or, accurate:
segs  = load_mfa_textgrid("voice.TextGrid")
track = generate_from_alignment(segs)
write_json(track, "track.json")

Preview what you generated

examples/preview.html is a self-contained page (no server needed) that animates a schematic mouth from a track and plots every viseme channel with a scrubbing playhead. Rebuild it for your own track:

python tools/build_preview.py track.json preview.html

The built-in previewer playing a track generated from examples/voice.wav — schematic articulator on the left, the exported viseme curves with a scrubbing playhead on the right. Try it live.

Output format

Deliberately trivial JSON (CSV also available) — sparse [time, value] keys per viseme channel, weights in [0, 1]. The full shape, abbreviated:

{
  "format": "openfacefx.track", "version": 1, "fps": 60.0, "duration": 1.6,
  "viseme_set": ["sil", "PP", "FF", "TH", "DD", "kk", "CH", "SS", "nn", "RR", "aa", "E", "I", "O", "U"],
  "channels": [
    { "name": "sil", "keys": [[0.0, 0.6196], [0.0833, 0.6644], /* … */] }
    // one object per active viseme channel
  ]
}

Channel names are blendshape names your rig exposes; linear interpolation between keys is the intended playback. See docs/COMPATIBILITY.md for a ~15-line reference reader.

Plugging in a real aligner (stage 1)

The naive aligner spaces phonemes by duration priors — fine for prototyping, not for shipping. For production accuracy, produce a list of PhonemeSegment(phoneme, start, end) from any of these and pass it to generate_from_alignment:

• Montreal Forced Aligner — best accuracy; parser included (load_mfa_textgrid).
• Gentle — Kaldi-based, JSON output; write a ~15-line adapter.
• wav2vec2 / Whisper — phoneme or word timings from a neural model; word-level needs no transcript.

Better G2P: drop in the full CMU Pronouncing Dictionary with G2P().load_cmudict("cmudict.dict") (the built-in dictionary is a tiny seed).

FaceFX ecosystem compatibility

We surveyed every public FaceFX wrapper on GitHub. The short version: all of them are parallel audio+text generators, not curve consumers — none accepts any lip-sync tool's curves as input, so "drop-in" compatibility is impossible by design, for us and everyone else. What is possible is writing the artifacts their pipelines consume:

Ecosystem	Route	Status
Unity / VRChat / Ready Player Me	-o clip.anim — AnimationClip with viseme_* or vrc.v_* blendshape curves	✅ shipped
Live2D Cubism (VTuber 2D)	-o mouth.motion3.json — parameter curves; mouth-open by default, per-vowel via --live2d-params, or auto-targeted from a model3.json LipSync group	✅ shipped
Godot 4	-o lipsync.tres — AnimationPlayer resource, one blend_shapes/* value track per viseme (--godot-node/--godot-naming)	✅ shipped
ARKit / Rhubarb / VRM / CC4 rigs	--retarget arkit|rhubarb|vrm|cc4 weighted remaps (docs)	✅ shipped
Unreal (official FaceFX-UE4/UE5 plugins)	Impossible via the plugins (proprietary .ffxc compiler); instead drive UE float curves / morph targets from JSON — the arkit remap feeds MetaHuman's ARKit route	✅ JSON today
Bethesda modding (Nukem9/FaceFXWrapper, xVASynth, Mantella)	.fuz container + .lip header tools (openfacefx.bethesda), plus an experimental clean-room Skyrim .lip writer (-o out.lip from naive/mfa): the payload was reverse-engineered and our codec re-encodes the real samples byte-exact — but it is not yet verified in-game (#12)	🧪 experimental writer shipped — needs in-game confirmation
Anything else	Trivial JSON/CSV + documented remap	✅ today

Full survey with per-tool details: docs/COMPATIBILITY.md.

Roadmap

The full backlog lives in the issues (milestone v0.2.0), distilled from a feature-gap survey against FaceFX.

• Unity AnimationClip exporter (-o clip.anim, oculus/vrchat naming)
• Live2D motion3.json (#20) and Godot .tres (#21) exporters
• Published remap tables: ARKit-52, Rhubarb, Preston-Blair, VRM, CC4
• Component-based coarticulation with tunable articulator timing (#1)
• Data-driven weighted phoneme→target mapping (#2)
• Batch directory processing with QA reports (#3)
• [~] Bethesda .LIP exporter — experimental Skyrim writer shipped (-o out.lip; re-encodes the real samples byte-exact, in-game verification pending) (#12)
• Prosody, gestures, events, text tags, i18n (#4–#8)

Scope & honesty

This is a working foundation, not a finished product. It gives you the full phoneme→viseme→curve→export chain and a preview, with a clean seam where a real acoustic aligner plugs in. Not yet included: emotion layering, a rig authoring GUI, audio feature-driven coarticulation (it's timing-driven), and engine plugins beyond JSON/CSV. All of these fit on top of FaceTrack without changing the solver. It does not read or write proprietary FaceFX binary formats (.facefx, .fxa, .fxe, .ffxc).

Layout

src/openfacefx/
  phonemes.py       ARPAbet inventory
  g2p.py            word → phonemes (CMUdict + rule fallback)
  alignment.py      PhonemeSegment, NaiveAligner, MFA TextGrid parser
  timing.py         TTS phoneme/viseme timing adapters (from-timing) ← skip the aligner
  anchors.py        word/segment-anchored naive alignment (SRT + TTS word timings)
  visemes.py        viseme set + phoneme→viseme map
  mapping.py        weighted phoneme→target mapping (JSON)  ← remap phonemes here
  coarticulation.py component dominance blending, CoartParams ← the interesting math
  curves.py         keyframe reduction, FaceTrack
  io_export.py      JSON / CSV writers
  export_unity.py   Unity .anim AnimationClip writer
  export_live2d.py  Live2D Cubism motion3.json parameter-curve writer
  export_godot.py   Godot 4 .tres AnimationPlayer resource writer
  export_cues.py    Rhubarb TSV/XML/JSON, Moho/OpenToonz .dat, Papagayo .pgo cues
  retarget.py       viseme→rig remapping + presets          ← retarget rigs here
  bethesda.py       .fuz container / .lip header tools
  export_lip.py     Bethesda Skyrim .lip writer (EXPERIMENTAL, #12) ← unverified in-game
  batch.py          directory batch runner + QA summary
  energy.py         audio-loudness fallback lip-sync (no transcript) ← amplitude-driven
  pipeline.py       orchestration
  cli.py            command line
tests/test_core.py  run: pytest
tools/              HTML previewer builder + viseme-gallery SVG renderer
docs/               logo, images, viseme gallery, quickstart tape, compatibility survey

CI runs the test suite plus CLI and preview-builder smoke tests on every push, across Linux / Windows / macOS on Python 3.9, 3.12 and 3.13.

License

MIT — see LICENSE.

FaceFX® is a registered trademark of OC3 Entertainment, Inc. OpenFaceFX is an independent project — not affiliated with, endorsed by, or connected to OC3 Entertainment or Speech Graphics — and contains no code or data from FaceFX products.
