A GPU-accelerated micromagnetic and ultrafast-thermal simulator built in Rust, optimized for 2D van-der-Waals ferromagnets like Fe₃GeTe₂. It supports standard LLG and opt-in thermal LLB pathways, complete with optical driving and a real-time visualization dashboard
A GPU-accelerated micromagnetic + ultrafast-thermal simulator targeting
nanostructured 2D van-der-Waals ferromagnets (Fe₃GeTe₂ in particular).
Implements the Landau–Lifshitz–Gilbert (LLG) equation as a default path
and the Landau–Lifshitz–Bloch (LLB) equation with a Koopmans M3TM
thermal-bath coupling as an opt-in path. Adds a phonon→substrate sink
(F2-prep), field-dependent equilibrium magnetisation m_e(T, B) (F1),
two-timescale longitudinal LLB with a proxy variable (F2), and
Beer-Lambert per-layer optical absorption (F3).
Calibrated against Zhou et al. Natl. Sci. Rev. 12, nwaf185 (2025) at the literal experimental operating point (T = T_c = 210 K, B = 1 T, F = 0.24 mJ/cm²) with loss 0.0002.*
- Default path: projected Heun LLG on a 2D + multilayer-z grid. Bit-stable against pre-thermal baseline.
- Thermal/LLB path: opt-in via
--enable-thermal/--enable-llb. Per-cell (T_e, T_p, |m|, m_target) state evolved by Koopmans M3TM electron+phonon dynamics + a phenomenological two-stage longitudinal relaxation toward the field-dependent equilibriumm_e(T, B). - Optical drive: up to 4 simultaneous laser pulses with Gaussian spatial + temporal profiles. Pulses can carry coherent IFE field, an M3TM thermal source (with absorbed fluence), or both. F3 Beer-Lambert per-layer absorption profile for multilayer studies.
- Observability: dashboard with 8 cyclable heatmap fields including live 2D-FFT k-space view, plus a 4×2 grid mode that shows all fields simultaneously. Status panel reports time, integrator, thermal state, current field range.
This is a reduced micromagnetic model, not a general-purpose simulator like OOMMF or MuMax3. It explicitly omits:
- Demagnetisation field — out of scope; magnetostatics deferred.
- Lateral heat diffusion (∇²T) — single-cell or grid cells are thermally isolated. Multi-cell hot-spot studies trap heat indefinitely.
- Stochastic thermal LLB (Langevin noise) — deterministic integration only.
- Full Atxitia LLB longitudinal torque — the χ_∥-coupled effective- field form. The shipped form is phenomenological exponential relaxation toward a target. The χ_∥ table is computed and bound on the GPU but currently unread.
See docs/physics.md §6 for the full limitations
list and docs/calibration.md §4 for the trust-
boundary discussion of the calibrated FGT preset.
# Default LLG run, FGT-bulk on vacuum, 256² grid, 10k steps.
cargo run --release --bin magnonic-sim -- --steps 10000 --interval 100
# Beaurepaire Ni canonical benchmark (1-line CLI).
./target/release/magnonic-sim --benchmark beaurepaire-ni
# Interactive dashboard with grid mode (all 8 fields visible).
cargo build --release --bin magnonic-dashboard --features gui
./target/release/magnonic-dashboard --grid --nx 128 --ny 128
# Engage thermal + LLB at runtime via CLI flags.
./target/release/magnonic-dashboard --grid \
--enable-llb --thermal-preset fgt-zhou --t-ambient 210 --bz 1.0
# Inside the dashboard: Space to run, L to fire IFE pulse, V to cycle fields.docs/usage.md covers the full CLI surface and the
dashboard keymap.
All passing:
| Gate | Result | Source |
|---|---|---|
| LLG byte-for-byte when thermal off | exact | min_norm/max_norm cols |
| GPU M3TM vs host (Ni 1 mJ/cm²) | 1.0e-6 / 9.5e-7 | examples/test_m3tm_gpu_vs_host.rs |
| LLB → LLG at T = 0 K | 1.5e-4 (avg_mz residual) | examples/test_sp4_proxy.rs |
| Energy balance (Beaurepaire + substrate sink) | 1.000 ± 0.001 | examples/test_beaurepaire_ni.rs |
| Pump-probe distinct responses | 3 amplitudes | examples/test_pump_probe.rs |
| F1 m_e field-dependence monotone | PASS | lib unit test |
| F2 collapsed = F1 single-stage | gap = 0.0000 | examples/test_llb_two_stage.rs |
| F3 Beer-Lambert top/bot split | 360 K @ δ=14 nm | examples/test_optical_skin_depth.rs |
| Zhou recalibration at literal T = T_c | demag 77.6%, rec@22ps 55.2%, loss 0.0002 | examples/test_zhou_fgt_calibrate.rs |
| 12 lib unit tests | 12/12 | cargo test --release --lib |
cargo build --release --bins --examples is warning-free.
┌──────────────────────────────┐
│ SimConfig (host, Rust) │
│ ├ Stack (layers, materials) │
│ ├ Substrate │
│ ├ Geometry (nx, ny, dx) │
│ ├ B_ext, j_current │
│ └ PhotonicConfig │
│ ├ pulses: Vec<LaserPulse>│
│ └ thermal: Option<...> │
└──────────┬───────────────────┘
│ effective() + GpuParams
▼
┌──────────────────────────────────────────────────────────────────┐
│ GPU buffers (binding group, 12 entries) │
│ │
│ 0 params (uniform, 736 B) ────────────────────────────┐ │
│ 1 mag (cell × vec4 m, 16 B/cell) │ │
│ 2 mag_pred (Heun predictor scratch) │ │
│ 3 h_eff (B_eff scratch) │ │
│ 4 torque_0 / 5 torque_1 (Heun stages) │ │
│ 6 temp_e (electron T per cell) ◀─── M3TM ──┐│ │
│ 7 temp_p (phonon T per cell) ◀───────────┤│ │
│ 8 m_reduced (M3TM |m| or mirror of |mag|) ◀─────────┤│ │
│ 9 m_e_table (2D, [T,B], read-only) ──────────┤│ │
│ 10 chi_par_table (2D, [T,B], read-only, F1)──────────┤│ │
│ 11 m_target (F2 proxy, |m| chases this) ◀─────────┘│ │
│ │ │
└──────────────────────────────────────────────────────────────────┘
│
┌──────────────┴───────────────┐
▼ ▼
┌────────────────────┐ ┌────────────────────┐
│ LLG path │ │ LLB+M3TM path │
│ (default, │ │ (opt-in) │
│ thermal=None) │ │ │
│ │ │ advance_m3tm: │
│ 4 pipeline pass: │ │ update Te,Tp,m_target
│ ft_phase0, │ │ ft_phase0_llb │
│ heun_predict, │ │ llb_predict │
│ ft_phase1, │ │ ft_phase1_llb │
│ heun_correct │ │ llb_correct │
│ │ │ │
│ |m| stays │ │ |m| varies │
│ unit-norm │ │ with thermal │
└────────────────────┘ └────────────────────┘
Detail: docs/physics.md.
Equations: docs/equations.md.
| Document | What's in it |
|---|---|
docs/physics.md |
Model, conventions, data flow, F-tier upgrades, limitations |
docs/equations.md |
Master list of every equation the code implements |
docs/usage.md |
CLI flags, dashboard keymap, preset library |
docs/calibration.md |
Zhou-2025 calibration procedure + how to fit new materials |
docs/references.md |
Bibliography (every cited paper) |
| Historical ADRs | Some comments reference prior ADRs; they are not part of this checkout |
src/
├── lib.rs module index
├── config.rs SimConfig, Stack, Layer, Geometry
├── material.rs BulkMaterial presets (FGT, Py, YIG, CoFeB, ...)
├── material_thermal.rs LayerThermalParams presets + 2D Brillouin tables
├── substrate.rs Substrate presets (vacuum, Pt, WTe2, YIG, ...)
├── effective.rs (BulkMaterial × Substrate × Geometry) → effective params
├── photonic.rs LaserPulse, PhotonicConfig, ThermalConfig
├── thermal.rs Host-side M3TM reference integrator (test oracle)
├── metrics.rs FFT / Q-factor / decay-time analysis for the sweep harness
├── gpu.rs GpuSolver (wgpu), buffer layout, dispatch
├── shaders/llg.wgsl All compute kernels: LLG, LLB, M3TM, advance_m3tm
├── main.rs magnonic-sim CLI
└── bin/
├── sweep.rs magnonic-sweep parametric sweep harness
├── dashboard.rs magnonic-dashboard interactive viewer
└── dashboard_text.rs 5×7 bitmap font + draw helpers
examples/ holds the regression-gate / acceptance probes
(test_m3tm_gpu_vs_host, test_sp4_proxy, test_pump_probe,
test_llb_two_stage, test_optical_skin_depth,
test_zhou_fgt_calibrate, ...).
# Headless binaries (default, fast).
cargo build --release --bins
# GUI dashboard (requires X / Wayland and the `gui` feature).
cargo build --release --bin magnonic-dashboard --features gui
# Unit tests.
cargo test --release --lib
# All acceptance probes.
for e in test_m3tm_gpu_vs_host test_sp4_proxy test_llb_reduces_to_llg \
test_llb_ni_demag test_pump_probe test_llb_two_stage \
test_optical_skin_depth test_beaurepaire_ni; do
cargo run --release --example $e
done
# Zhou re-calibration (longest, ~13 min on RTX 4060).
cargo run --release --example test_zhou_fgt_calibrateInternal research code; no public license attached.
Closest architectural analog: Boris (Lepadatu 2020). Calibration target:
Zhou et al. (2025). All references in docs/references.md.
